Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
3300 |
|
Model/Part Number |
330130-080-00-IN |
|
Model Type |
3300 XL Standard Extension Cable |
Mechanical Specifications
|
Component |
Specifications |
|---|---|
|
Probe Tip Material |
Polyphenylene sulfide (PPS) |
|
Probe Case Material |
AISI 303 or 304 Stainless Steel (SST) |
|
Probe Cable (Standard) |
75Ω triaxial, fluoroethylene propylene (FEP) insulated |
|
Probe Cable (Extended Temp.) |
75Ω triaxial, perfluoroalkoxy (PFA) insulated |
|
Available Probe Lengths |
0.5, 1, 1.5, 2, 3, 5, or 9 meters |
|
Armor (Optional on Both) |
Flexible AISI 302 or 304 SST with FEP outer jacket |
|
Tensile Strength (Max Rated) |
330 N (75 lbf) probe case to probe lead |
|
270 N (60 lbf) at probe lead to extension cable connectors |
|
|
Connector Material |
Gold-plated brass or gold-plated beryllium copper |
Length and Weight
|
Component |
Specifications |
|---|---|
|
System Length |
5 or 9 meters (including extension cable) or 1 meter (probe only) |
|
Total System Weight |
0.7 kg (1.5 lbm) |
|
Probe Weight |
323 g/m (11.4 oz) |
|
Extension Cable Weight |
34 g/m (0.4 oz/ft) |
|
Armored Extension Cable Weight |
103 g/m (1.5 oz/ft) |
|
Proximitor Sensor Weight |
246 g (8.67 oz) |
Ordering Information for Extension Cables
|
Attribute |
Options |
|---|---|
|
Model Number |
330130-AAA-BB-CC |
|
A: Cable Length Option |
030 - 3.0 meters (9.8 feet) |
|
035 - 3.5 meters (13.1 feet) |
|
|
040 - 4.0 meters (11.5 feet) |
|
|
045 - 4.5 meters (14.8 feet) |
|
|
060 - 6.0 meters (19.7 feet) |
|
|
070 - 7.0 meters (22.9 feet) |
|
|
075 - 7.5 meters (24.6 feet) |
|
|
080 - 8.0 meters (26.2 feet) |
|
|
085 - 8.5 meters (27.9 feet) |
|
|
B: Connector Protector and Cable Option |
00 - Standard cable |
|
01 - Armored cable |
|
|
02 - Standard cable with connector protector |
|
|
03 - Armored cable with connector protector |
|
|
10 - FluidLoc cable |
|
|
11 - Armored FluidLoc cable |
|
|
12 - FluidLoc cable with connector protector |
|
|
13 - Armored FluidLoc cable with connector protector |
|
|
C: Agency Approval Option |
00 - Not required |
|
05 - CSA, ATEX, IECEx Approvals |
