Bently Nevada 3500/25-01-01-00 149369-01+125800-02 3500/25 Enhanced Keyphasor Module
Bently Nevada 3500/25-01-01-00 149369-01+125800-02 3500/25 Enhanced Keyphasor Module
Manufacturer: Bently Nevada
Product No.: 149369-01+125800-02
Condition:1000 in stock
Product Type: 3500/25 Enhanced Keyphasor Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 460g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
3500/25-01-01-00 |
|
Spare Part Numbers |
149369-01 (Keyphasor Module) / 125800-02 (Isolated I/O) |
|
Description |
3500/25 Enhanced Keyphasor Module |
|
Series |
3500 |
_
_
__ Description
The_3500/25 Enhanced Keyphasor Module_is a_half-height,_two-channel_module that provides Keyphasor signals to the monitor modules in a 3500 rack. It processes inputs from proximity probes or magnetic pickups and converts them into digital Keyphasor signals.
The system can handle:
_
-
Up to_four Keyphasor signals_in a normal configuration.
-
Up to_eight signals_in a paired configuration.
The part number_3500/25-01-01-00_corresponds to:
_
-
01_= 2-channel Keyphasor card
-
01_= I/O Module with_Internal Terminations
-
00_= No agency approval
_
_
__ Environmental Limits
|
Parameter |
Value |
|---|---|
|
Operating Temperature |
-30°C to +65°C (non-barrier I/O)0°C to +65°C (barrier I/O) |
|
Storage Temperature |
-40°C to +85°C |
|
Humidity |
95%, non-condensing |
_
_
__ Physical Specifications
|
Component |
Dimensions (H x W x D) |
Weight |
|---|---|---|
|
Main Module |
119.9 mm x 24.4 mm x 256.5 mm (4.72 x 0.96 x 10.10 in) |
0.34 kg (0.76 lbs) |
|
I/O Module |
241.3 mm x 24.4 mm x 103.1 mm (9.50 x 0.96 x 4.06 in) |
0.46 kg (1.01 lbs) |
_
_
__ Ordering Information
3500/25-AA-BB-CC
|
Field |
Option |
Description |
|---|---|---|
|
A |
01 |
Single 2-channel Keyphasor module |
|
02 |
Two 2-channel Keyphasor modules (for 4-channel use) |
|
|
B |
01 |
I/O Module with Internal Terminations |
|
02 |
I/O Module with External Terminations |
|
|
03 |
Internal Barrier I/O with Internal Terminations |
|
|
04 |
Isolated I/O (Internal Terminations, for Magnetic Pickups) |
|
|
05 |
Isolated I/O (External Terminations, for Magnetic Pickups) |
|
|
C |
00 |
No approval |
|
01 |
cNRTLus (Class 1, Div 2) |
|
|
02 |
ATEX/IECEx/CSA (Class 1, Zone 2) |
_
_
__ Spares
|
Part Number |
Description |
|---|---|
|
149369-01 |
Enhanced Keyphasor Module |
|
125800-02 |
Isolated Keyphasor I/O Module with Internal Terminations (Mag Pickups) |
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| Bently Nevada | 3500/42M Proximitor/Seismic Monitor (09-00, 176449-02 + 140471-01) | _1807-2807_ | 300 | Proximitor/Seismic Monitor |
| Bently Nevada | 3500/15 AC and DC Power Supplies (04-04-01) | _1807-2807_ | 400 | AC and DC Power Supplies |
| Bently Nevada | 3500/15 Power Supply Module (133292-01) | _1774-2774_ | 500 | Power Supply Module |
| Bently Nevada | 3500/45 Position Monitor (176449-04) | _1766-2766_ | 600 | Position Monitor |
| Bently Nevada | 3500/93 Display Interface Module (07-01-02-00, 135799-01) | _1724-2724_ | 700 | Display Interface Module |
| Bently Nevada | 3500/93 System Display (07-04-02-00) | _1724-2724_ | 200 | System Display |
