Bently Nevada 330130-070-00 3300 XL Standard Extension Cable
Bently Nevada 330130-070-00 3300 XL Standard Extension Cable
Manufacturer: Bently Nevada
Product No.: 330130-070-00
Condition:1000 in stock
Product Type: 3300 XL Standard Extension Cable
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
3300 |
|
Model/Part Number |
330130-070-00 |
|
Model Type |
3300 XL Standard Extension Cable |
Electrical Specifications
|
Parameter |
Details |
|---|---|
|
Proximitor Sensor Input |
Accepts one non-contacting_3300-series 5 mm, 3300 XL 8 mm Proximity Probe and Extension Cable |
|
Extension Cable Capacitance |
69.9 pF/m (21.3 pF/ft) typical |
|
Connector Material |
Gold-plated brass or gold-plated beryllium copper |
|
Maximum Connector Torque |
0.565 N_m (5 in_lbf) |
Extension Cable Material
|
Cable Type |
Insulation Material |
|---|---|
|
Standard Cable |
75Ω triaxial, fluoroethylene propylene (FEP) insulated |
|
Extended Temperature Range Cable |
75Ω triaxial, perfluoroalkoxy (PFA) insulated |
__Minimum Cable Bend Radius:_25.4 mm (1.0 in)
__Interchangeability: 3300 XL 8 mm components are both_electrically and physically interchangeable_with non-XL_3300 5 mm and 8 mm components, provided the_minimum permissible cable bend radius_is observed.
Physical Specifications
|
Parameter |
Value |
|---|---|
|
System Length |
5 or 9 meters_(including extension cable) or_1 meter_(probe only) |
|
Total System Weight (Typical) |
0.7 kg (1.5 lb) |
|
Probe Weight |
323 g/m (11.4 oz) |
|
Extension Cable Weight |
34 g/m (0.4 oz/ft) |
|
Armored Extension Cable Weight |
103 g/m (1.5 oz/ft) |
|
Proximitor Sensor Weight |
246 g (8.67 oz) |
Ordering Information
|
Part Number |
Description |
|---|---|
|
330130 |
3300 XL Standard Extension Cable |
Part Number Format:
330130-AAA-BB-CC
|
Option Code |
Description |
|---|---|
|
A: Cable Length Option |
030 =_3.0 meters (9.8 feet)__035 =_3.5 meters (13.1 feet)__040 =_4.0 meters (11.5 feet)__045 =_4.5 meters (14.8 feet)__060 =_6.0 meters (19.7 feet)__070 =_7.0 meters (22.9 feet)__075 =_7.5 meters (24.6 feet)__080 =_8.0 meters (26.2 feet)__085 =_8.5 meters (27.9 feet) |
|
B: Connector Protector and Cable Option |
00 = Standard cable__01 = Armored cable__02 = Standard cable with connector protector__03 = Armored cable with connector protector__10 = FluidLoc cable__11 = Armored FluidLoc cable__12 = FluidLoc cable with connector protector__13 = Armored FluidLoc cable with connector protector |
|
C: Agency Approval Option |
00 = Not required__05 = CSA, ATEX, IECEx Approvals |
_
