Product Description
🔹 General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Series |
3300 5 mm Transducer System |
|
Model/Part Number |
330173-00-02-10-12-00 |
|
Description |
3300 5 mm Probe, M8 x 1 thread, without armor |
🔹 Description
The 3300 5 mm Proximity Transducer System consists of:
• 3300 5 mm Probe
• 3300 XL Extension Cable (Reference: 141194-01)
• 3300 XL Proximitor Sensor (Reference: 141194-01)
This system provides accurate and reliable non-contact measurement of shaft vibration and displacement in rotating machinery applications.
🔹 Specifications
|
Parameter |
Value |
|---|---|
|
Thread Type |
M8 x 1 |
|
Unthreaded Length (A) |
02 = 20 mm |
|
Overall Case Length (B) |
02 = 20 mm |
|
Total Length (C) |
10 = 1.0 meter (3.3 feet) |
|
Connector Type (D) |
12 = Miniature ClickLoc coaxial connector, FluidLoc cable |
|
Agency Approval (E) |
00 = No agency approval required |
|
Tensile Strength |
222 N (50 lbf) at probe case and lead |
|
Weight |
323 g (11.39 oz) |
🔹 Ordering Information
Model Number Format: 330173-AA-BB-CC-DD-EE
|
Code |
Selection |
Description |
|---|---|---|
|
A: Unthreaded Length Option |
02 |
20 mm |
|
B: Overall Case Length Option |
02 |
20 mm |
|
C: Total Length Option |
10 |
1.0 meter (3.3 feet) |
|
D: Connector Type |
12 |
Miniature ClickLoc coaxial connector, FluidLoc cable |
|
E: Agency Approval Option |
00 |
No approval required |
