Product Description
Product Overview
- The Bently Nevada 3300/12-02-20-00 is an AC Power Supply from the 3300/12 series, designed to deliver reliable, regulated power to up to 12 monitors and their associated transducers within a 3300 rack system. This module, installed in the left-most rack position, eliminates the need for a second power supply in the same rack, providing an efficient and dependable power solution for industrial monitoring applications.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 3300/12 |
| Model/Part Number | 3300/12-02-20-00 |
| Model Type | AC Power Supply |
| Inputs - Power | 95 to 125 Vac, single phase, 50 to 60 Hz, at 1.0 A maximum or 190 to 250 Vac, single phase, 50 to 60 Hz, at 0.5 A maximum Field-changeable via soldered jumper and replacement of external fuse |
| Primary Power Surge at Powerup | 26 A peak, or 12 A rms, for one cycle |
| Fuse Rating | 95 to 125 Vac: 1.5 A slow blow 190 to 250 Vac: 0.75 A slow blow |
| Operating Temperature | 0°C to +65°C (+32°F to +150°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | To 95%, non-condensing |
| Space Requirements | One rack position, installs only in position one (left-most position, next to System Monitor) |
| Weight | 1 kg (2.2 lbs) |
Ordering Information
- Model: 3300/12 AC Power Supply
- Ordering Format: 3300/12-AXX-BXX-CXX
- Option Descriptions:
- A: Input Voltage Option
- 01: 95-125 Vac 50/60 Hz
- 02: 190-250 Vac 50/60 Hz
- Note: Input Voltage Option is field-changeable; ordering determines factory shipment configuration only
- B: Power Input Module Option
- 20: Standard
- 22: Internal Safety Barriers
- 23: Spare supply only - No PIM
- C: Agency Approval Option
- 00: Not Required
- 01: CSA/NRTL/C
- 02: ATEX self-certification
- A: Input Voltage Option
Specific Configuration
- Model/Part Number: 3300/12-02-20-00
- Configuration Details:
- A: 02 - Input Voltage: 190-250 Vac 50/60 Hz
- B: 20 - Power Input Module: Standard
- C: 00 - Agency Approval: Not Required
