Product Description
__ General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1746-P7 |
|
Description |
Power Supply Module for SLC 500 PLCs |
|
Product Series |
SLC 500 |
_
__ Power Supply Specifications
|
Attribute |
Specification |
|---|---|
|
Line Voltage |
10-30V DC (P7) |
|
Typical Line Power Requirement |
75 VA for 24V DC input, 50 VA for 12V DC input |
|
Maximum Inrush Current |
20A (required for turn-on) |
|
Internal Current Capacity |
3.6A at 5V DC, 0.87A at 24V DC (for 24V input) |
|
Fuse Protection |
Fuse is soldered in place |
|
24V DC User Power Current Capacity |
200 mA |
|
24V DC User Power Voltage Range |
18-30V DC |
|
Ambient Operating Temperature |
0°C to +60°C (+32°F to +140°F) (Current capacity is derated 5% above +55°C) |
|
Isolation |
600V AC RMS for 1s (P6), 1800V AC RMS for 1s (P5) |
|
CPU Hold-up Time |
1.37 ms at 0V (full load) for 12V input, 40 ms at 0V (full load) for 24V input |
_
__ Certifications
|
Certification |
|---|
|
UL Listed Industrial Control Equipment for Class 1, Division 2, Groups A, B, C, D Hazardous Locations |
|
CE, European Union 89/336/EEC EMC Directive, compliant with EN50082-2 (Industrial Immunity) |
|
C-Tick, Australian Radiocommunications Act |
_
