Product Description
🔹 General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1746-IG16 |
|
Description |
5V DC TTL Input Module |
🔹 Electrical Specifications
|
Attribute |
Specification |
|---|---|
|
Voltage Category |
5V DC TTL Signal Input (Sourcing) |
|
Number of Inputs |
16 |
|
Points per Common |
16 |
|
Operating Voltage Range |
+5V to DC COM: 4.5…5.5V DC (Sourcing) 50 mV Peak-to-Peak Ripple (Max) |
|
Backplane Current Consumption |
5V DC: 0.140 A 24V DC: 0.0 A |
|
Signal Delay (Max.) |
On: 0.25 ms Off: 0.50 ms |
|
Off-State Voltage |
2…5.5V DC(1) |
|
Off-State Current (Max.) |
4.1 mA |
|
Input Current (Nominal) |
3.7 mA @ 5V DC |
