1SDA054126R1 | ABB TMAX T4S 320 3P 400V 50KA MCCB

1SDA054126R1 | ABB TMAX T4S 320 3P 400V 50KA MCCB

  • Manufacturer: ABB

  • Product No.: 1SDA054126R1

  • Condition:1000 in stock

  • Product Type: Circuit Breaker

  • Product Origin: Sweden

  • Payment: T/T, Western Union

  • Weight: 3500g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Extended Product Type: T4S 320 PR221DS-I In=320 3p F F
Product ID: 1SDA054126R1
EAN: 8015644552251
Long Description: Circuit Breaker TMAX T4S 320 Fixed Three-Pole with Front Terminals and Solid-State Release in AC PR221DS-I R 320

Material Compliance

  • REACH Declaration: REACH Declaration for ABB Sace circuit breakers
  • RoHS Information: RoHS Declaration for ABB Sace circuit breakers
  • RoHS Status: Compliant with EU Directive 2011/65/EU and Amendment 2015/863 (July 22, 2019)
  • Conflict Minerals Reporting Template (CMRT): Document available on demand
  • Toxic Substances Control Act (TSCA): TSCA declaration

Environmental

  • Product Environmental Information: Available for Tmax T4 series

Ordering Information

  • E-Number (Finland): 3655514
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85362090

Dimensions

Dimension Value
Product Net Width 105 mm
Product Net Height 205 mm
Product Net Depth/Length 103.5 mm
Product Net Weight 3.5 kg

Packaging Information

Package Level Value
Package Level 1 Units 1 piece
Package Level 1 Width 248 mm
Package Level 1 Height 240 mm
Package Level 1 Depth/Length 285 mm
Package Level 1 Gross Weight 3.5 kg
Package Level 1 EAN 8015644552251

Product Specifications

Specification Value
Product Main Type SACE Tmax T
Product Name Moulded Case Circuit Breaker
Product Type Automatic Circuit Breaker
Suitable For Tmax T4
Electrical Durability 6000 cycles, 120 cycles per hour
Mechanical Durability 20000 cycles, 240 cycles per hour
Number of Poles 3
Power Loss 17.6 W per pole at rated conditions
Rated Current (In) 320 A
Rated Impulse Withstand Voltage (Uimp) 8 kV
Rated Insulation Voltage (Ui) 1000 V
Rated Operational Voltage 690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics) 85 kA at 220V AC, 50 kA at 380V AC, 25 kA at 690V AC
Rated Ultimate Short-Circuit Breaking Capacity (Icu) 85 kA at 220V AC, 50 kA at 380V AC, 25 kA at 690V AC
Rated Uninterrupted Current (Iu) 320 A
Release PR221DS-I
Release Type EL
Short-Circuit Performance Level S
Standards IEC
Terminal Connection Type Fixed Circuit-Breakers, Front
Test Voltage Max (Utest) 3500 V

Certificates and Declarations

  • Data Sheet, Technical Information: 1SDC210004D0203
  • Declaration of Conformity - CE: EC Declaration of Conformity for Tmax T4
  • GL Certificate: 1SDL000163R0061
  • Instructions and Manuals: Installation instructions for Tmax T4

Classifications

  • ETIM 8: EC000228 - Power circuit-breaker for transformer/generator/installation protection
  • UNSPSC: 39121100
  • WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
  • eClass: V11.1 : 27370409
