Product Description
Product Overview
The ABB DSQC346E is a Servo Drive Unit designed for use in ABB’s industrial robotic systems, specifically within the S4, S4C, and S4C+ controller platforms for robots such as the IRB 2400, IRB 4400, or IRB 6400 series. Manufactured by ABB, this module is a critical component of the robot’s drive system, controlling the servo motors that power the robot’s axes for precise motion. It is commonly used in applications like material handling, welding, and assembly in industries such as automotive manufacturing, electronics, and general automation. The DSQC346E is often associated with part number **3HAB8101-11**, with variants like 3HAB8101-11/08A indicating specific revisions. It is known for its reliability, compact design, and compatibility with ABB’s robotic controllers.
Technical Specifications
The DSQC346E has the following specifications based on supplier data and inferred characteristics from ABB robotics documentation:
| Item | Specification |
|---|---|
| Model/Part Number | DSQC346E (3HAB8101-11) |
| Manufacturer | ABB |
| Description | Servo Drive Unit |
| Series | S4 / S4C / S4C+ |
| Power Supply | 400-480 V AC, 50/60 Hz (via rectifier) |
| Output Power | Up to 1.5 kW (typical for IRB series servo motors) |
| Control Method | Vector control |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Weight | Approximately 3.31 kg (7.3 lbs) |
Additional Details
The DSQC346E includes the following additional information based on its standard use and supplier documentation:
| Category | Details |
|---|---|
| Function | Drives servo motors for robot axis control |
| Mounting | Installed in S4C controller rack |
| Connectivity | Interfaces with robot controller and motor cabling |
| Features | High reliability, precise motion control, compact design |
| Certifications | Designed for industrial standards (e.g., CE) |
