Product Description
Product Details
| Manufacturer | ABB |
|---|---|
| Model/Part Number | DO524 |
| Product ID | 1SAP240700R0001 |
| Catalog Description | Digital Output Module, 32 DO: 24VDC 0.5A (DO524) |
| Product Name | Distributed Automation I/Os |
| Product Main Type | DO524 |
| Function | 32 DO: 24VDC 0.5A |
| Output Type | Transistor |
| Degree of Protection | IP20 |
| Supply Voltage | 20.4 … 28.8 V DC |
Ordering Information
| CN8 Code | 85389091 |
|---|---|
| Invoice Description | Digital Output Module, 32 DO: 24VDC 0.5A (DO524) |
| Made To Order | No |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Selling Unit of Measure | Piece |
Weight & Dimensions
| Specification | Value |
|---|---|
| Product Net Weight | 0.106 kg |
| Gross Weight | 0.13 kg |
| Product Net Depth / Length | 62 mm |
| Product Net Height | 76 mm |
| Product Net Width | 67.5 mm |
| Package Level 1 Depth / Length | 84 mm |
| Package Level 1 Height | 72 mm |
| Package Level 1 Width | 71 mm |
| Package Level 1 Units | 1 carton |
Technical Specifications
| Specification | Value |
|---|---|
| Number of Digital Outputs | 32 |
| Number of Digital Configurable I/Os | 0 |
| Output Voltage Type | DC |
| Output Current | 0.5 A |
| Output Voltage Range | 20.4 … 28.8 V |
External Classifications & Standards
| eClass | 27-24-22-04 |
|---|---|
| ETIM 8 / 9 / 10 | EC001419 - PLC digital I/O-module |
| UNSPSC | 32151705 |
Environmental Information
| SCIP | 16b29f4e-e363-43ca-ad6f-2d21b7f75cfa Germany (DE) |
|---|---|
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
