Product Description
General Information
Product Identification
| Attribute | Details |
|---|---|
| Extended Product Type | PM5072-T-2ETH |
| Product ID | 1SAP124500R0073 |
| ABB Type Designation | PM5072-T-2ETH |
| EAN | 4013614551734 |
| Catalog Description | Processor module. Memory 8MB. 12 DI 24 VDC. 8 DO 24 VDC 0.5A. 2 DC 24 VDC. 2 Ethernet interfaces. 3 option slots (PM5072-T-2ETH) |
| Long Description | PM5072-T-2ETH: AC500-eCo Processor module. Memory 8MB. 12 DI 24 VDC. 8 DO 24 VDC 0.5A. 2 DC 24 VDC. 2 Ethernet interfaces. 3 option slots. |
Ordering Information
| Attribute | Details |
|---|---|
| CN8 | 85371091 |
| Invoice Description | Processor module. Memory 8MB. 12 DI 24 VDC. 8 DO 24 VDC 0.5A. 2 DC 24 VDC. 2 Ethernet interfaces. 3 option slots (PM5072-T-2ETH) |
| Made To Order | No |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Selling Unit of Measure | piece |
Dimensions
| Attribute | Details |
|---|---|
| Product Net Weight | 0.265 kg |
| Product Net Depth / Length | 74 mm |
| Product Net Height | 135 mm |
| Product Net Width | 82 mm |
| Gross Weight | 0.307 kg |
| Package Level 1 Depth / Length | 100 mm |
| Package Level 1 Height | 95 mm |
| Package Level 1 Width | 175 mm |
| Package Level 1 Units | 1 carton |
Technical Information
| Attribute | Details |
|---|---|
| Function | Memory 8MB. 12 DI 24 VDC. 8 DO 24 VDC 0.5A. 2 DC 24 VDC. 2 Ethernet interfaces. 3 option slots |
| Number of Hardware Interfaces | Industrial Ethernet 2 |
| Memory Size | 9100 kB |
| Memory Type User Data | RAM |
| Controller Processing Time | 0.00002 ms |
| Number of Digital Inputs | 12 |
| Number of Digital Outputs | 8 |
| Number of Digital Configurable I/Os | 2 |
| Input Voltage Type | DC |
| Degree of Protection | IP20 |
| Rated Voltage (Ur) | 24 V DC |
| Supply Voltage | 20.4 … 28.8 V DC |
Additional Information
| Attribute | Details |
|---|---|
| Product Main Type | PM5072 |
| Product Name | Distributed Automation PLCs |
External Classifications and Standards
| Attribute | Details |
|---|---|
| eClass | 27-24-22-07 |
| ETIM 8 | EC000236 - PLC CPU-module |
| ETIM 9 | EC000236 - PLC CPU-module |
| ETIM 10 | EC000236 - PLC CPU-module |
| UNSPSC | 32151705 |
Environmental
| Attribute | Details |
|---|---|
| SCIP | 0c6f902e-769c-40b6-a7ae-b47a067a7eb1 Germany (DE) |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
