Product Description
Product Details
- Manufacturer: ABB
- Model/Part Number: CAI20-P (3BDH000722R1)
- Description: Analog Input Module
General Information
| Attribute | Details |
|---|---|
| Product ID | 3BDH000722R1 |
| ABB Type Designation | CAI 20-P |
| Catalog Description | CAI 20-P, Analog Input |
| Long Description | CAI 20-P, Analog Input, SW Version 1.31 or later - 32 Inputs: 0/4–20 mA, 0/2–10 V, Re 250 Ohm, HART - Isolation per module, Transmitter Power Supply - Necessary Accessories: 4 pcs. CI 100/101, Cable Clamp |
| Product Type | I/O Module |
Ordering & Logistics
| Attribute | Details |
|---|---|
| HS Code | 853890 – Parts suitable for use with electrical control or distribution equipment |
| Customs Tariff Number | 85389099 |
| Battery Included | No |
| SCIP Code (EU Compliance) | 5de9e0da-4dde-4f82-b8a7-5a91e1875171 |
Dimensions & Weight
| Attribute | Details |
|---|---|
| Product Net Depth / Length | 212 mm |
| Product Net Height | 350 mm |
| Product Net Width | 55 mm |
| Product Net Weight | 0.76 kg |
Technical & Environmental Information
| Attribute | Details |
|---|---|
| Channel Type | Analog Input (AI) |
| Number of Input Channels | 32 |
| Signal Types Supported | 0/4–20 mA, 0/2–10 V, HART |
| Isolation | Per module |
| Transmitter Power Supply | Yes |
| RoHS Status | Compliant with EU Directive 2011/65/EU |
| WEEE Category | Category 5 - Small Equipment (No External Dimension More Than 50 cm) |
