Yokogawa SEA4D-01 Analog Terminal Board
Yokogawa SEA4D-01 Analog Terminal Board
Manufacturer: Yokogawa
Product No.: SEA4D-01
Condition:1000 in stock
Product Type: Analog Terminal Board
Product Origin: Japan
Payment: T/T, Western Union
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Parameter |
Value |
|---|---|
|
Manufacturer |
Yokogawa |
|
Model/Part Number |
SEA4D-01 |
|
Product Description |
Analog Terminal Board (Single and Dual-Redundant, 16 channels x 2) |
|
Application |
For analog signals in single/dual-redundant configurations |
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Number of Connection Channels |
16 channels _ 2 |
|
Terminal Type |
M4 screw |
|
Safety Integrity Level (SIL) |
SIL3 |
|
Connection Module |
SAI143 |
|
Connection Cable |
KS1 |
|
Weight |
1.5 kg |
|
Withstand Voltage |
500 V AC (for 1 minute) (*5) |
|
Insulation Resistance |
100 MΩ minimum (500 V DC) |
Model and Suffix Codes
|
Suffix Code |
Description |
|---|---|
|
-0 |
Without surge absorber |
|
-1 |
With surge absorber |
|
6 |
With ISA Standard G3 and no explosion protection |
|
F |
With ISA Standard G3 and explosion protection |
Option Codes
|
Option Code |
Description |
|---|---|
|
/NTRY |
Without cable tray |
