Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Yokogawa |
| Model/Part Number | EB511-10 S2 |
| Description | Bus Interface Module (Style S2) designed for Yokogawa CENTUM series Distributed Control Systems, enabling high-speed communication between field control stations and field devices for advanced process automation |
| Key Features | High-speed bus communication, CENTUM CS 3000 and VP compatibility, real-time data transfer, enhanced reliability, Style S2 hardware revision |
Technical Specifications
| Specification | Details |
|---|---|
| Model | EB511-10 S2 |
| Product Type | Bus Interface Module |
| Series | CENTUM (CS 3000, CENTUM VP) |
| Communication | Vnet/IP or proprietary Yokogawa bus protocol |
| Power Supply | Typically 24 VDC (via system backplane) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Weight | Approx. 0.3-0.5 kg (0.66-1.1 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Bus connection to CENTUM Field Control Station (FCS), interfaces with field devices via I/O modules |
Functional Features
| Feature | Details |
|---|---|
| Data Acquisition | Collects real-time data from field devices and transmits to DCS |
| Control Command Transmission | Sends control signals from DCS to field devices |
| Compatibility | Integrates with CENTUM CS 3000 and CENTUM VP systems |
| Reliability | Enhanced design (Style S2) for high availability in process control |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | EB511-10 |
| Configuration | S2: Style 2 revision, updated hardware variant |
