Yokogawa AI-917-00 Analogue Input Module
Yokogawa AI-917-00 Analogue Input Module
Manufacturer: Yokogawa
Product No.: AI-917-00
Condition:1000 in stock
Product Type: Analogue Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Overview
The Yokogawa AI-917-00 is an Analogue Input Module designed to process 4 analogue inputs and provide 4 outputs. Housed in a single Euro format, it supports both current and voltage inputs and features programmable functionality, making it a compact and versatile solution for industrial control applications.
Technical Specifications
The AI-917-00 Analogue Input Module has the following specifications:
| Item | Specification |
|---|---|
| Model | AI-917-00 |
| No. of Inputs | 4 |
| No. of Outputs | 4 |
| Size | Single Euro format 4TE (160 x 100 x 20 mm) |
| Connector | DIN 41612 Bauform F 48p |
| Identification | AI-917 on front |
| Temperature (Working) | -10 to +60 °C |
| Temperature (Storage) | -25 to +85 °C |
| Relative Humidity | Max. 75%, no condensation |
| EMC | EN 61000-6-2 Immunity EN 61000-6-4 Emission With an EMC system enclosure |
| Shock | 15g, 11 ms |
| Vibration | 10-55 Hz 0.075 mm, 57-150 Hz 1 g (0.076-0.011 mm) |
| Input |
Current: 0 - 20 mA, 50 Ω (max. 50 mA) Voltage: 0 - 10 V, 5.5 kΩ (max. 30 V) |
| Switches | (3) partly programmable |
| Stability Error | < 0.1% / 10°C |
| Accuracy | ± 0.2% ± 1 bit |
| Resolution | 1024 points over 21.6 mA / 10.8 V (10 bits) |
| LED Test | 18-30 V / 3.5-6 mA |
| Clock | Clock pulses from MC-573, level 0/11 V |
| Output | Pulse logic Current Pulses: 500 mA Capacity: 10 unit loads |
| Status Indication | Programmable LEDs |
| Data | 8 bits serial data, level 0/11 V |
| Display | LCD, programmable 2 Rows: First row - numeric value, Second row - 1 alpha, 2 numeric characters |
| RS232 Serial Interface | For programming only (adapter cable necessary) |
| Propagation |
Start-up Time: 8 s Program Cycle: 40 ms (program dependent) Delay: Programmable |
| Supply |
Field Supply: 18-30 Vdc (ripple < 1 V top-top), 70 mA (24 V) Logic Supply: 20 Vdc, 10 mA Clock Signal: A voltage pulse |
| Isolation | Analog circuit 0.5 kV (test) |
| Dissipation | 2 W |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | SSB401-13 S1 ESB Bus Interface Slave Module | 500-1072 | 495 | SSB401-13 S1 ESB Bus Interface Module |
| YOKOGAWA | PW702 S1 Power Supply Module | 643-1643 | 324 | PW702 S1 Power Supply Module |
| YOKOGAWA | CP334D S3 Process Controller | 500-1500 | 264 | CP334D S3 Process Controller |
| YOKOGAWA | AAI543-H53/A4D00 Analog Input Module | 1500-2500 | 280 | AAI543-H53/A4D00 Analog Input Module |
| YOKOGAWA | EC402-51-S1 ESB Bus Coupler Module | 1214-2214 | 433 | EC402-51-S1 ESB Bus Coupler Module |
| YOKOGAWA | CP471-00 S1 Processor Module | 4500-5500 | 978 | CP471-00 S1 Processor Module |
| YOKOGAWA | NFAR181-S00 S2 RTD Input Module | 929-1929 | 101 | NFAR181-S00 S2 RTD Input Module |
