Yokogawa AAI143-S53 S1 Analog Input Module
Yokogawa AAI143-S53 S1 Analog Input Module
Manufacturer: Yokogawa
Product No.: AAI143-S53 S1
Condition:1000 in stock
Product Type: Analog Input Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI143-S53 S1 |
|
Description |
Analog Input Module (4 to 20 mA, 16-channel, Isolated) with G3 environmental option |
_
_
__ Description
The_AAI143-S53 S1_is a high-performance 16-channel_isolated analog input module_designed for industrial process automation applications. It accepts_4 to 20 mA_current signals and is capable of being configured in_dual-redundant systems. This model includes extended_environmental protection (G3)_and operates in a_wider temperature range.
The___53_ suffix_indicates:
_
-
Standard type
-
No explosion protection
-
ISA G3 conformal coating
-
Wider temperature range: -20 to +70 °C
The___1__tag typically refers to a_hardware revision or series identification, often used to track firmware compatibility, manufacturing batch, or specific factory customization.
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
AAI143 |
|
Input Channels |
16, isolated |
|
Input Signal |
4 to 20 mA |
|
Allowable Input Current |
24 mA |
|
Withstanding Voltage |
1500 V AC (1 minute, input to system) |
|
Input Resistance (Power ON) |
270 _ (at 20 mA) to 350 _ (at 4 mA) |
|
Input Resistance (Power OFF) |
_500 k_ |
|
Accuracy |
±16 µA |
|
Data Update Period |
10 ms |
|
Transmitter Power Supply |
_19.0 V @ 20 mA; _25.5 V @ 0 mA (limit: 25 mA) |
|
Transmitter Type Setting |
Per channel, via setting pin (2-wire / 4-wire) |
|
Temp Drift |
±16 µA per 10 °C |
|
Max Current Consumption |
230 mA @ 5 V DC; 540 mA @ 24 V DC |
|
Weight |
0.3 kg |
|
External Communication |
Pressure clamp terminal, MIL connector, KS1 cable |
|
HART Communication |
Available (not included in standard -S version) |
_
_
__ Model Configuration
|
Suffix Code |
Meaning |
|---|---|
|
S |
Standard Type |
|
5 |
No explosion protection |
|
3 |
With ISA G3 conformal coating and -20 to +70 °C temperature range |
|
S1 |
Hardware/firmware or production series identifier |
_
_
