Yokogawa AAI543-H53-S1 Analog Output Module
Yokogawa AAI543-H53-S1 Analog Output Module
Manufacturer: Yokogawa
Product No.: AAI543-H53-S1
Condition:1000 in stock
Product Type: Analog Output Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI543-H53-S1 |
|
Description |
Analog Output Module (4_20 mA, 16-channel, Isolated, HART, G3 option) |
_
_
__ Specifications
|
Item |
Description |
|---|---|
|
Number of Output Channels |
16, isolated |
|
Output Signal |
4 to 20 mA |
|
Redundancy Support |
Standard switch-over response in redundant configuration |
|
Withstanding Voltage |
1500 V AC (between output and system for 1 minute) |
|
Allowable Load Resistance |
0 to 750 _ |
|
Circuit-open Detection |
Less than 0.65 mA |
|
Accuracy |
±48 µA |
|
Data Update Period |
10 ms |
|
Ambient Temperature Drift |
±16 µA per 10°C |
|
Maximum Current Consumption |
230 mA @ 5 V DC, 540 mA @ 24 V DC |
|
Weight |
Approx. 0.4 kg |
|
External Communication |
Pressure clamp terminal, MIL connector cable, or KS1 dedicated cable |
|
HART Communication |
Supported (suffix_H) |
_
_
__ Model & Suffix Code Breakdown
|
Model |
Meaning |
|---|---|
|
AAI543 |
Analog Output Module (16-channel, 4_20 mA, Isolated) |
|
-H |
With HART digital communication |
|
5 |
Standard switch-over response in redundant configuration |
|
3 |
With ISA G3 standard and temperature range: _20 to 70 °C |
|
-S1 |
Likely a variant or internal option code (e.g., firmware or system-specific version) |
_
_
__ Optional Accessories (as needed)
|
Option Code |
Description |
|---|---|
|
/K4A00 |
KS Cable Interface Adapter [ATK4A-00] |
|
/A4S00 |
Pressure Clamp Terminal Block [ATA4S-00] |
|
/A4S10 |
Pressure Clamp Terminal Block with Surge Absorber [ATA4S-10] |
|
/A4D00 |
Dual Pressure Clamp Terminal Block [ATA4D-00] |
|
/A4D10 |
Dual Pressure Clamp Terminal Block with Surge Absorber [ATA4D-10] |
|
/CCC01 |
Connector Cover for MIL Cable [ACCC01] |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | FU20-10-T1-NPT Combination pH Sensor for Process Monitoring | 429_1429 | 390 | FU20-10-T1-NPT pH Sensor |
| YOKOGAWA | SDV144-S53 Digital Input Module for 16 Channels | 655_1655 | 740 | SDV144-S53 Digital Input Module |
| YOKOGAWA | AAI543-H50/A4S10 Analog Output Module for Current Signals | 857_1857 | 510 | AAI543-H50/A4S10 Analog Output Module |
| YOKOGAWA | PW484-51 Power Supply Module for DCS Systems | 714_1714 | 870 | PW484-51 Power Supply Module |
| YOKOGAWA | NFAI543-500/A4500 Associated Terminal Block for Analog Output | 429_1429 | 430 | NFAI543-500/A4500 Terminal Block |
| YOKOGAWA | YS170-012/A06/A31 Single-Loop Programmable Controller | 1357_2357 | 690 | YS170-012/A06/A31 Controller |
| YOKOGAWA | AAI543-S50/A4S10 Analog Output Module | 714-1714 | 784 | AAI543-S50/A4S10 Analog Output Module |
