Yokogawa AAI543-H00 S1 Analog Output Module
Yokogawa AAI543-H00 S1 Analog Output Module
Manufacturer: Yokogawa
Product No.: AAI543-H00 S1
Condition:1000 in stock
Product Type: Analog Output Module
Product Origin: Japan
Payment: T/T, Western Union
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
AAI543-H00 S1 |
|
Description |
Analog Output Module (4_20 mA, 16-channel, Isolated, HART, Redundant Support) |
_
_
__ Description
The_AAI543-H00 S1_is a_16-channel analog output module_designed to provide_4_20 mA isolated signals_with support for_dual-redundant configurations. This specific variant includes_HART digital communication_support, making it suitable for applications requiring remote diagnostics and configuration.
_
_
__ Technical Specifications
|
Specification |
Details |
|---|---|
|
Model |
AAI543 |
|
Output Channels |
16, isolated _ supports standard switch-over in redundant configuration |
|
Output Signal |
4 to 20 mA |
|
Withstanding Voltage |
1500 V AC (output _ system), 1 minute |
|
Allowable Load Resistance |
0 to 750 _ |
|
Circuit-Open Detection |
Less than 0.65 mA |
|
Accuracy |
±48 µA |
|
Data Update Period |
10 ms |
|
Temperature Drift |
±16 µA per 10 _C |
|
Max Current Consumption |
230 mA (5 V DC), 540 mA (24 V DC) |
|
Weight |
0.4 kg |
|
External Communication |
Pressure clamp terminal, MIL connector, KS1 cable |
|
HART Communication |
Available_(included in this model:_-H) |
_
_
__ Model Breakdown
|
Code |
Meaning |
|---|---|
|
-H |
With digital communication (HART protocol) |
|
0 |
Basic type (no ISA G3 or extended temperature range) |
|
S1 |
Internal designation, often denotes software/firmware version or hardware revision |
_
_
__ Optional Accessories (Available if Needed)
|
Option Code |
Description |
|---|---|
|
/K4A00 |
KS Cable Interface Adapter [ATK4A-00] |
|
/A4S00 |
Pressure Clamp Terminal Block [ATA4S-00] |
|
/A4S10 |
Pressure Clamp Terminal Block with Surge Absorber [ATA4S-10] |
|
/A4D00 |
Dual Pressure Clamp Terminal Block [ATA4D-00] |
|
/A4D10 |
Dual Pressure Clamp Terminal Block with Surge Absorber [ATA4D-10] |
|
/CCC01 |
Connector Cover for MIL Cable [ACCC01] |
_
_
| Check below popular items for more information in_ | Industrial Control Hub | |||
| Brand | Description | _Price (USD)_ | Stock | Link |
| YOKOGAWA | SEC401-11 S2 ESB Bus Coupler Module for DCS | 716_1716 | 690 | SEC401-11 S2 ESB Bus Coupler Module |
| YOKOGAWA | AFV30D-A41252 Duplexed Field Control Unit for Redundant Systems | 3786_4786 | 320 | AFV30D-A41252 Field Control Unit |
| YOKOGAWA | ADV151-P00 S2 Digital Input Module for 32 Channels | 500_1000 | 760 | ADV151-P00 S2 Digital Input Module |
| YOKOGAWA | AAI543-S53 Analog Output Module for Current Output | 1143_2143 | 590 | AAI543-S53 Analog Output Module |
| YOKOGAWA | ALP111-S00 S1 PROFIBUS-DP Communication Module for DCS | 1500_2500 | 410 | ALP111-S00 S1 PROFIBUS-DP Module |
| YOKOGAWA | AFV30D-S41151 Duplexed Field Control Unit for High Availability | 3786_4786 | 680 | AFV30D-S41151 Field Control Unit |
| YOKOGAWA | ANB10D-420 Node Unit for Dual Redundant ESB Bus | 3071_4071 | 330 | ANB10D-420 Node Unit |
