Yokogawa AAI135-H50/K4A00 Analog Input Module

Yokogawa AAI135-H50/K4A00 Analog Input Module

  • Manufacturer: Yokogawa

  • Product No.: AAI135-H50/K4A00

  • Condition:1000 in stock

  • Product Type: Analog Input Module

  • Product Origin: Japan

  • Payment: T/T, Western Union

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

The Yokogawa AAI135-H50K4A00 is an Analog Input Module designed for precise current signal acquisition in industrial control systems. Part of the Current Input Module and Current I/O Module series, this module features 8 isolated channels for 4 to 20 mA inputs and supports dual-redundant configurations. With HART communication and a KS Cable Interface Adapter, it offers robust performance and flexibility, making it a key component in Yokogawa__ automation solutions.

Technical Information

Item Specifications
Manufacturer Yokogawa
Model/Part Number AAI135-H50K4A00
Description Analog Input Module
Number of I/O Channels 8-channel input, isolated channels
I/O Signal 4 to 20 mA
Allowable Input Current 25 mA
Withstanding Voltage Between input and system: 500 V AC, for 1 minute
Between input channels: 500 V AC, for 1 minute (*2)
Input Resistance Power ON: 290 _ (at 20 mA) to 450 _ (at 4 mA) (*3)
Power OFF: 500 k_ or larger
Accuracy ±16 µA
Data Update Period 10 ms
Transmitter Power Supply 15.0 V or higher (at 20 mA)
29.3 V or less (at 0 mA) (*5)
Temperature Drift ±16 µA/10 °C
Maximum Current Consumption 360 mA (5 V DC), 450 mA (24 V DC)
Weight 0.3 kg
External Connection Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
HART Communication (*6) Available

Model and Suffix Codes

  • Model: AAI135 Analog Input Module (4 to 20 mA, 8-channel, Isolated channels)
  • Suffix Codes:
    • -S: Standard type
    • -H: With digital communication (HART protocol)
    • 5: With no explosion protection
    • E: With explosion protection
    • 0: Basic type
    • 3: With ISA Standard G3 option and temperature (-20 to 70 °C) option
  • Option Codes:
    • /13A00: With KS Cable Interface Adapter [Model: ATI3A-00]
    • /K4A00: With KS Cable Interface Adapter [Model: ATK4A-00]
    • /13S00: With Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3S-00]
    • /13S10: With Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3S-10]
    • /13D00: With Dual Pressure Clamp Terminal Block for Isolated Analog [Model: ATI3D-00]
    • /13D10: With Dual Pressure Clamp Terminal Block for Isolated Analog (surge absorber) [Model: ATI3D-10]
    • /CCC01: With Connector Cover for MIL Cable [Model: ACCC01]

Specific Configuration

  • Model/Part Number: AAI135-H50K4A00
  • Configuration Details:
    • -H: With digital communication (HART protocol)
    • 5: With no explosion protection
    • 0: Basic type
    • /K4A00: With KS Cable Interface Adapter [Model: ATK4A-00]
