Product Description
Product Overview
The ABB TU616 is a Terminal Unit Module designed for use with the ABB AC500 Programmable Logic Controller (PLC) series. Manufactured by ABB, a global leader in electrification and automation, this module serves as a base for connecting I/O modules to the AC500 PLC system, providing a reliable interface for field wiring and signal distribution. While not exclusively a turbine control system component, the TU616 can be integrated into turbine automation setups within ABB’s broader control solutions, such as the I/A Series or Symphony Plus, when paired with appropriate controllers and I/O cards. It supports industrial applications including power generation, process automation, and turbine control, offering a modular, DIN-rail-mountable design for flexibility and ease of installation. The TU616 ensures robust connectivity and efficient signal management in harsh industrial environments.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | ABB |
| Series | AC500 PLC |
| Model/Part Number | TU616 |
| Description | Terminal Unit Module |
| Function | Base for I/O module connection and field wiring |
| Connection | Screw terminals, supports up to 10 I/O points |
| Power Supply | 24 Vdc (via AC500 bus) |
| Operating Temperature | -25 °C to +60 °C (-13 °F to +140 °F) |
| Dimensions | 135 mm H x 67.5 mm W x 62 mm D (5.31 in x 2.66 in x 2.44 in) |
| Weight | 0.14 kg (0.31 lb) |
