Triconex 7400195-210 9771-2XX Analog Input Termination Panel

Triconex 7400195-210 9771-2XX Analog Input Termination Panel

Product Overview

• The Triconex 7400195-210 9771-2XX is an Analog Input Termination Panel designed for Triconex safety instrumented systems (SIS) by Schneider Electric. Belonging to the Triconex Other Modules series, this panel connects field devices to Triconex analog input modules, supporting reliable signal transmission for safety-critical operations in triple modular redundant (TMR) architectures. It is used in industries such as oil and gas, chemical, and power generation.

Technical Specifications

• The 7400195-210 9771-2XX has the following specifications based on standard characteristics for this model:

Additional Details

• The 7400195-210 9771-2XX includes the following additional information based on its standard use and documentation:
• Function: Interfaces field devices, such as 4-20 mA transmitters, with Triconex analog input modules (e.g., 3700, 3700A, 3703E, 3721), supporting safety monitoring and control in TMR systems.
• Compatibility: Compatible with Triconex Tricon and Tricon CX systems; designed for use with analog input modules and cables like 4000103-510.
• Configuration: Features terminal blocks for secure field wiring and a multi-pin connector for reliable I/O module connection; supports TMR fault tolerance with jumper options for sharing field transmitters with other systems (e.g., DCS).
• Certifications: Meets CE, UL, and industrial standards for safety and performance in hazardous environments.
• Part Type: Available as new, surplus, or refurbished.
• Features: Compact design for DIN rail mounting; robust construction for harsh industrial environments; supports reliable signal integrity for safety-critical applications.
