Product Description
Triconex 4000093-317 External Termination Cable
Product Overview
- The Triconex 4000093-317 is an External Termination Cable designed for Triconex safety instrumented systems (SIS) by Schneider Electric. This cable connects Triconex I/O modules to external termination panels, enabling reliable signal transmission for safety-critical operations. It is used in triple modular redundant (TMR) architectures to ensure fault-tolerant communication in industries such as oil and gas, chemical, and power generation.
Technical Specifications
- The 4000093-317 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 4000093-317 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | External Termination Cable |
| Series | Tricon, Tricon CX |
| Cable Type | Signal Transmission Cable |
| Length | 17 meters (55.77 feet) |
| Conductor Count | Typically 16 conductors (for 16-channel I/O modules) |
| Connector Type | Custom Triconex multi-pin connector |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Weight | Approx. 1-2 kg (depending on configuration) |
Additional Details
- The 4000093-317 includes the following additional information based on its standard use and documentation:
- Function: Transmits critical process data between Triconex I/O modules and external termination panels, supporting digital and analog signals for safety monitoring and control in SIS applications.
- Applications: Used in chemical plants, oil refineries, and power generation facilities to connect safety sensors (e.g., pressure, temperature) to the SIS for real-time monitoring.
- Compatibility: Compatible with Triconex Tricon and Tricon CX systems, interfacing with I/O modules and termination panels in TMR configurations.
- Configuration: Designed for secure signal transmission with high-quality shielding to minimize electromagnetic interference; supports TMR architecture for fault tolerance.
- Certifications: Meets CE, UL, and other industrial standards for safety and performance in hazardous environments.
