Product Description
Product Overview
|
Category |
Details |
|---|---|
|
Manufacturer |
Triconex (Schneider Electric) |
|
Model/Part Number |
3510 |
|
Description |
Pulse Input Module designed for Triconex Safety Instrumented Systems, delivering 8-channel pulse input processing for SIL 3 safety applications |
Key Features
-
8 pulse input channels
-
SIL 3 certified (IEC 61508, TÜV)
-
Triple Modular Redundant (TMR) architecture
-
High-speed pulse counting up to 20 kHz
-
Real-time diagnostics and fault tolerance
-
Compatible with Tricon control systems
Technical Specifications
|
Specification |
Details |
|---|---|
|
Model |
3510 |
|
Product Type |
Pulse Input Module |
|
Series |
Tricon |
|
Number of Inputs |
8 channels |
|
Input Type |
Pulse (dry contact, 24 VDC) |
|
Frequency Range |
Up to 20 kHz |
|
Safety Integrity Level |
SIL 3 (IEC 61508, TÜV certified) |
|
Power Supply |
24 VDC (via system backplane) |
|
Operating Temperature |
0°C to 60°C (32°F to 140°F) |
|
Weight |
Approx. 0.5–0.7 kg (1.1–1.5 lbs) |
External Connection Options
|
Connection Type |
Details |
|---|---|
|
Terminal Blocks |
For pulse signal field wiring |
|
System Interface |
Connects to Tricon system via standard backplane architecture |
Functional Features
|
Feature |
Details |
|---|---|
|
Pulse Processing |
High-speed counting and signal conditioning for pulse-type inputs |
|
Fault Tolerance |
Triple Modular Redundancy ensures uninterrupted function during failures |
|
Diagnostics |
Built-in, real-time diagnostics and health monitoring |
|
Configuration |
Configured using TriStation 1131 software |
Model and Configuration
|
Category |
Details |
|---|---|
|
Base Model |
3510 |
|
Configuration |
Standard type for Triconex pulse inputs |
