Emerson VE4001S2T2B5 40-Pin Mass Termination Block for DeltaV DI Card
Emerson VE4001S2T2B5 40-Pin Mass Termination Block for DeltaV DI Card
Manufacturer: Emerson
Product No.: VE4001S2T2B5
Condition:1000 in stock
Product Type: Mass Termination Block
Product Origin: 6954789023458
Payment: T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Emerson VE4001S2T2B5 40-Pin Mass Termination Block for DeltaV Discrete Input Systems
The Emerson VE4001S2T2B5 is a factory-engineered 40-pin mass termination block designed specifically for 32-channel discrete input cards in DeltaV M-series distributed control architectures. This industrial-grade wiring interface eliminates point-to-point field connections, reducing installation time by up to 60% while ensuring consistent signal integrity across high-density digital I/O applications.
Key Technical Features
- Pin Configuration: 40-position spring-clamp terminals with color-coded wire guides
- Channel Capacity: Supports up to 32 discrete input channels plus common returns
- Wire Gauge Compatibility: 14-26 AWG solid or stranded copper conductors
- Contact Material: Tin-plated copper alloy for corrosion resistance
- Insertion Force: Tool-free spring-release mechanism for rapid wire insertion/removal
- Voltage Rating: 250 VAC/VDC maximum per circuit
- Current Rating: 10A continuous per terminal at 40°C ambient
- Insulation Resistance: >100 MΩ at 500 VDC
- Operating Temperature: -40°C to +85°C extended range
- Flammability Rating: UL94 V-0 flame-retardant housing
- Certifications: UL, CSA, CE, ATEX Zone 2, IECEx for hazardous locations
Industrial Application Solutions
Emergency Shutdown Systems (ESD): Deploy in safety-critical applications requiring rapid field device status monitoring—limit switches, emergency stop buttons, pressure switches, and flame detectors connect directly to SIL-rated DeltaV logic solvers through this termination interface.
Motor Control Centers (MCC): Interface motor starter auxiliary contacts, thermal overload relays, and circuit breaker status signals to DeltaV controllers for comprehensive motor protection and sequencing logic in pump stations, compressor trains, and conveyor systems.
Valve Position Monitoring: Aggregate open/closed feedback from pneumatic and electric actuators across multi-valve manifolds, enabling real-time valve position verification for batch processes, pipeline switching, and blending operations.
Alarm Annunciation: Consolidate discrete alarm inputs from field instruments, analyzers, and auxiliary equipment into centralized DeltaV alarm management systems with time-stamped event logging and priority-based operator notification.
Installation & Maintenance Advantages
The VE4001S2T2B5 features a modular snap-on design that mounts directly to DeltaV I/O carriers without additional mounting hardware. Pre-labeled terminal positions correspond to DeltaV I/O channel assignments, eliminating wiring errors during commissioning. The spring-clamp technology withstands vibration environments up to 5g without terminal loosening, making it ideal for skid-mounted equipment and offshore platforms.
Hot-swappable architecture allows field wiring to remain connected during I/O card replacement—simply unplug the termination block from the old card and reconnect to the new module, reducing mean time to repair (MTTR) by 75% compared to screw-terminal alternatives. Built-in test points enable in-situ signal verification with multimeters or oscilloscopes without disturbing field connections.
System Compatibility & Integration
Fully compatible with Emerson VE4001 series discrete input cards including VE4001S2T2B4, VE4001S2T2B5, and VE4001S5T2B4 variants. Integrates with DeltaV VE4050 8-wide carriers, VE4070 LocalBus isolators, and redundant I/O configurations for high-availability process control. Supports both simplex and redundant controller architectures with automatic failover capabilities.
Works seamlessly with DeltaV versions 11.3 through 15.1 LTS, including DeltaV Live operator interfaces, AMS Device Manager for asset diagnostics, and DeltaV SIS safety instrumented systems. Compatible with third-party field devices via industry-standard 24 VDC discrete signal protocols.
Related DeltaV I/O Components
| Product Model | Description | Product Link |
|---|---|---|
| VE4001S2T2B5 | 32-Channel Discrete Input Module for DeltaV | View Product |
| VE4001S2T2B4 | Discrete Input Module with Enhanced Diagnostics | View Product |
| VE4002S1T2B6 | 32-Channel Discrete Output Card for DeltaV | View Product |
Quality & Warranty
Each VE4001S2T2B5 termination block undergoes 100% continuity testing and high-potential (hipot) dielectric strength verification before shipment. Supplied with installation documentation, terminal labeling sheets, and wire ferrule recommendations. Backed by a 24-month manufacturer warranty covering material defects and workmanship under normal operating conditions.
