Emerson SE4305T01 KL3002X1-BA1 24VDC Digital Input CHARM Module
Emerson SE4305T01 KL3002X1-BA1 24VDC Digital Input CHARM Module
Manufacturer: Emerson
Product No.: KL3002X1BA1
Condition:1000 in stock
Product Type: DI 24 VDC Dry Contact CHARM
Product Origin: 6954789034567
Payment: T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Emerson SE4305T01 KL3002X1-BA1 24VDC Digital Input CHARM Module for DeltaV
The Emerson SE4305T01 KL3002X1-BA1 represents next-generation CHARM (CHARacterization Module) technology for high-density digital input acquisition in DeltaV M-series distributed control systems. This 32-channel 24VDC dry contact input module delivers exceptional signal integrity, advanced diagnostics, and space-efficient I/O density for monitoring discrete field devices including limit switches, pushbuttons, proximity sensors, and relay contacts across process industries.
CHARM Technology Advantages
CHARM I/O modules revolutionize DeltaV system architecture by integrating signal conditioning, diagnostics, and communication intelligence directly into compact field-mountable packages. The SE4305T01 reduces cabinet space requirements by 40% compared to traditional I/O cards while delivering superior noise immunity through integrated optical isolation and advanced filtering algorithms.
Key CHARM Benefits:
- High-density 32-channel configuration in compact form factor
- Integrated diagnostics with per-channel health monitoring
- Hot-swappable design for online maintenance without process interruption
- Reduced wiring complexity through distributed I/O architecture
- Enhanced EMI/RFI immunity for electrically noisy environments
Technical Specifications
| Input Channels | 32 independent 24 VDC dry contact inputs |
| Input Voltage Range | 10-30 VDC (logic high ≥15 VDC, logic low ≤5 VDC) |
| Input Current | 7 mA typical per channel at 24 VDC |
| Response Time | Configurable 1-100 ms digital filtering |
| Isolation | 1500 VAC channel-to-bus, 500 VAC channel-to-channel (groups of 8) |
| Diagnostic Coverage | Wire break detection, short circuit detection, power supply monitoring |
| Update Rate | 10 ms scan cycle with synchronized sampling |
| LED Indicators | Per-channel status LEDs plus module health indicator |
| Power Consumption | 4.5W maximum from DeltaV carrier backplane |
| Operating Temperature | -40°C to +70°C ambient |
| Humidity Range | 5-95% RH non-condensing |
| Certifications | UL/CSA Class I Div 2, ATEX Zone 2, IECEx, CE marked |
Industrial Application Scenarios
Safety Interlock Monitoring: Monitor emergency stop circuits, safety gate positions, light curtain status, and pressure relief valve positions in machine safety systems compliant with ISO 13849 and IEC 62061 functional safety standards.
Rotating Equipment Protection: Acquire vibration switch trips, bearing temperature alarms, lube oil pressure switches, and seal failure indicators from turbomachinery protection systems for gas turbines, steam turbines, and centrifugal compressors.
Valve Position Feedback: Monitor limit switch feedback from motor-operated valves (MOVs), pneumatic actuators, and hydraulic actuators to verify open/closed positions and detect mid-travel faults in critical isolation and control valves.
Batch Process Sequencing: Track discrete process states including tank level switches, agitator running status, pump seal flush pressure, and filter differential pressure switches in pharmaceutical and specialty chemical batch manufacturing.
Alarm Annunciation: Consolidate field alarm contacts from standalone instruments, analyzers, and packaged equipment into centralized DeltaV alarm management for unified operator interface and historical event logging.
Advanced Diagnostic Capabilities
The KL3002X1-BA1 CHARM module employs intelligent diagnostics that continuously monitor input signal quality, power supply voltage, and communication health. Wire break detection identifies open-circuit faults even when field devices are de-energized, enabling proactive maintenance before process upsets occur. Configurable digital filtering eliminates contact bounce and electrical noise while maintaining fast response times for critical safety inputs.
Per-channel LED indicators provide instant visual feedback during commissioning and troubleshooting, reducing startup time by 25% compared to modules without local diagnostics. Module-level health monitoring integrates with DeltaV AMS Suite for predictive maintenance alerts and asset performance tracking.
System Integration & Architecture
Designed for seamless integration with DeltaV M-series controllers (MD, MD Plus, MQ, MX) via high-speed LocalBus communication. Compatible with VE3051C0 power/controller carriers, KL4104X1 dual-wide carriers, and VE4070 LocalBus isolators for flexible system architectures. Supports DeltaV versions 11.3 through 15.1 LTS with full backward compatibility for system expansions and upgrades.
CHARM modules enable distributed I/O topologies that position signal conditioning closer to field devices, reducing wiring costs and improving signal integrity in large-scale installations spanning multiple process units or geographic areas.
Related DeltaV Controller Products
| Product Model | Description | Product Link |
|---|---|---|
| Emerson VE3008 | DeltaV MQ Controller (High-Performance) | View Product |
| Emerson VE3007 KJ2005X1-BA2 | DeltaV MX Controller (Standard Performance) | View Product |
| Emerson DST1401I | DeltaV System Controller (Workstation Interface) | View Product |
Installation & Commissioning Support
Factory-configured modules ship with pre-loaded firmware and default I/O mapping templates for rapid deployment. Comprehensive documentation includes wiring diagrams, terminal block layouts, and configuration examples for common applications. Spring-clamp terminal blocks accept 12-24 AWG wire without ferrules, accelerating field termination and reducing installation errors.
Backed by 18-month warranty covering manufacturing defects and performance specifications. Global technical support provides configuration assistance, diagnostic troubleshooting, and system integration guidance for complex multi-controller architectures.
