Emerson KJ4005X1-BC1 Power Terminal Plug for DeltaV S-Series
Emerson KJ4005X1-BC1 Power Terminal Plug for DeltaV S-Series
Manufacturer: Emerson
Product No.: KJ4005X1-BC1
Condition:1000 in stock
Product Type: Power Terminal Plug
Product Origin: 6954789023458
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Emerson KJ4005X1-BC1 Power Terminal Plug for DeltaV S-Series Carriers
The Emerson KJ4005X1-BC1 Power Terminal Plug delivers robust, field-proven power distribution for DeltaV S-series carrier modules in mission-critical process automation environments. Engineered with 12-amp current capacity and multi-voltage compatibility, this terminal plug ensures reliable power delivery to I/O cards, controllers, and communication modules across oil & gas, chemical, pharmaceutical, and power generation facilities.
Key Technical Parameters
- Current Rating: 12 Amps continuous per terminal
- Voltage Support: 24V DC / 120V AC / 230V AC selectable
- Terminal Configuration: Individual power connections for isolated circuits
- Contact Material: Tin-plated copper alloy for corrosion resistance
- Wire Gauge Compatibility: 14-22 AWG (0.5-2.5 mm²)
- Connection Type: Spring-clamp screw terminals with captive hardware
- Insulation Rating: 600V AC/DC maximum
- Operating Temperature: -40°C to +85°C
- Vibration Resistance: IEC 60068-2-6 compliant for industrial shock/vibration
- Certifications: UL, CSA, CE, ATEX Zone 2, IECEx for hazardous locations
Industrial Application Solutions
Distributed Control System (DCS) Power Architecture: Deploy in multi-carrier DeltaV cabinets to establish isolated power zones for analog I/O, discrete I/O, and communication modules, preventing ground loops and electrical noise propagation in large-scale process control networks.
Redundant Power Supply Integration: Configure dual KJ4005X1-BC1 plugs with separate 24V DC sources to create fault-tolerant power distribution for SIL-rated safety systems, ensuring continuous operation during single-point power failures in critical shutdown logic.
Hazardous Area Installations: Utilize in Zone 2/Division 2 classified areas for intrinsically safe barrier power feeds, supporting explosion-proof enclosures in upstream oil & gas wellhead monitoring, refinery tank farms, and chemical reactor control panels.
Retrofit & Modernization Projects: Replace legacy power terminal blocks in aging DeltaV systems without rewiring entire cabinets—backward-compatible design maintains pin-out consistency with earlier S-series carrier generations, reducing downtime during plant upgrades.
Design & Installation Advantages
The KJ4005X1-BC1 features tool-free removal with integrated locking tabs, enabling hot-swappable maintenance during scheduled outages without de-energizing adjacent circuits. Color-coded terminal markings and laser-etched voltage ratings minimize wiring errors during commissioning. The plug's low-profile design accommodates high-density carrier installations in space-constrained control cabinets.
Spring-clamp terminals eliminate torque-wrench requirements and maintain consistent contact pressure across temperature cycling, reducing maintenance intervals by up to 50% compared to traditional screw terminals. Built-in strain relief prevents conductor fatigue in high-vibration turbomachinery environments.
System Compatibility Matrix
Compatible with DeltaV S-series carriers including KL4104X1 dual carriers, KJ4110X1 IS extenders, and VE4070 LocalBus isolators. Supports DeltaV versions 8.3 through 15.1 LTS with full backward compatibility for legacy system integration. Works seamlessly with KJ1501X1 dual power supplies and KJ150X1 redundant power modules.
Related DeltaV Components
| Product Model | Description | Product Link |
|---|---|---|
| KJ3206X1-BK1 | S-Series DI 8-Channel 24 VDC Isolated Card | View Product |
| KJ3001X1-BA1 | Digital Input Card, 8-Channel, 24 VDC, Isolated | View Product |
| KJ3007X1-EA1 | ProfibusDP Terminal Block for Fieldbus Integration | View Product |
Quality & Compliance
Factory-tested to 100% electrical continuity and dielectric withstand voltage per IEC 61010-1 standards. Includes RoHS compliance certification and conflict minerals declaration. Backed by 18-month warranty covering material defects and workmanship. Technical support available for wiring diagrams, load calculations, and troubleshooting assistance.
© 2025 INDUSTRIAL CONTROL HUB. All rights reserved.
Original Source: https://www.indctrlhub.com
Contact: sales@indctrlhub.com | +0086 18359243191
