CMT1000 ABB Commissioning and Maintenance Tool for UNITROL 1000
CMT1000 ABB Commissioning and Maintenance Tool for UNITROL 1000
Manufacturer: ABB
Product No.: CMT1000
Condition:1000 in stock
Product Type: Commissioning and Maintenance Tool
Product Origin: 8506741293057
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
ABB CMT1000 Commissioning and Maintenance Tool - Professional Excitation System Support
The ABB CMT1000 is a specialized commissioning and maintenance tool engineered for comprehensive support of UNITROL 1000 excitation systems in synchronous generators and motors. This professional-grade diagnostic instrument delivers precise parameter configuration, real-time monitoring, and advanced troubleshooting capabilities for power generation facilities worldwide.
Technical Specifications
- Compatible Systems: UNITROL 1000 series excitation controllers
- Communication Interface: RS-232/RS-485 serial connection
- Operating Temperature: -10°C to +50°C
- Power Supply: External adapter or battery-powered operation
- Display: High-resolution LCD with intuitive menu navigation
- Data Logging: Built-in memory for parameter storage and event recording
Key Applications
Power Generation Commissioning: Streamline initial setup and calibration of UNITROL 1000 AVR systems during new generator installations, ensuring optimal voltage regulation from first startup.
Preventive Maintenance Programs: Execute scheduled diagnostic routines to verify excitation system performance, detect parameter drift, and validate protective function operation before issues impact generation availability.
Fault Diagnosis and Resolution: Rapidly identify excitation system anomalies through comprehensive alarm analysis, waveform capture, and parameter comparison against baseline configurations.
System Upgrades and Retrofits: Facilitate seamless parameter migration when upgrading legacy excitation systems or integrating UNITROL 1000 controllers into existing generator control architectures.
Advanced Features
The CMT1000 provides direct access to all UNITROL 1000 configuration parameters, enabling precision tuning of voltage regulator gain, excitation limiter thresholds, and protective relay settings. Real-time oscilloscope functionality captures transient events during load changes or fault conditions, supporting root cause analysis of voltage regulation disturbances.
Integrated data logging preserves historical parameter sets and alarm records, creating an audit trail for regulatory compliance and maintenance documentation. The tool's firmware update capability ensures compatibility with evolving UNITROL 1000 software releases.
Industry Solutions
Utility-scale power plants leverage the CMT1000 for commissioning multi-unit generating stations, where consistent excitation system configuration across parallel generators is critical for stable grid operation. Industrial cogeneration facilities utilize the tool to optimize excitation response during frequent load cycling and islanded operation modes.
Marine propulsion systems benefit from the CMT1000's portable design for shipboard generator maintenance, while renewable energy installations employ it for hybrid system integration where synchronous generators provide grid-forming capability alongside inverter-based resources.
Related Products
| Product | Description | Link |
|---|---|---|
| ABB UNITROL1010 AVR | 3BHE035301R1002 Automatic Voltage Regulator | View Product |
| ABB UNITROL 1020 Module | 3BHE030579R0003 Basic Converter Module for AVR | View Product |
| ABB UAD149A11 Controller | 3BHE014135R011 Excitation System Controller | View Product |
