Bently Nevada 3500/15 133292-01 Power Supply Module
Bently Nevada 3500/15 133292-01 Power Supply Module
Manufacturer: Bently Nevada
Product No.: 3500/15 133292-01
Condition:1000 in stock
Product Type: Low Voltage DC Power Supply Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 1390g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Product Details
| Manufacturer | Bently Nevada |
|---|---|
| Series | 3500/15 |
| Model/Part Number | 3500/15 133292-01 |
| Model Type | Power Supply Module |
Description
The 3500/15 AC and DC Power Supplies are half-height modules designed to fit into designated slots on the left side of the 3500 rack. These power supplies allow for a flexible configuration, enabling the rack to contain one or two power supplies of various combinations of AC and DC. Each supply is capable of powering a full rack.
Environmental Limits
| Condition | Temperature Range |
|---|---|
| Operating Temperature | -30 °C to +65 °C (-22 °F to +150 °F) |
| Storage Temperature | -40 °C to +85 °C (-40 °F to +185 °F) |
| Humidity | 95%, non-condensing |
Physical Specifications
| Component | Dimensions (H x W x D) | Weight |
|---|---|---|
| Power Supply Module | 120.7 mm x 50.8 mm x 251.5 mm (4.75 in x 2.0 in x 9.9 in) | 1.39 kg (3.06 lb) |
Specifications
| Input Voltage Options | Details |
|---|---|
| Universal Voltage AC | Input: 110 to 220 Vac nominal (non-hazardous areas) 85 to 264 Vac rms (non-hazardous) 85 to 250 Vac rms (hazardous) 120 to 373 Vac peak (for hazardous areas) Input Frequency: 47 to 63 Hz |
| Low Voltage DC | Input: 20 to 30 Vdc |
Current Information
-
Full Rack Current Draw:
- Universal AC: 2.8 A rms (maximum)
- High Voltage DC: 2.5 A (maximum)
- Low Voltage DC: 11.0 A (maximum)
-
Protection:
- Under-voltage: No damage to the supply or the Power Input Module (PIM).
- Over-voltage: Fuse opens on the PIM.
Ordering Information
| Model Format | 3500/15-AA-BB-CC |
|---|---|
| A: Power Supply Type (Top Slot) |
03: Legacy High Voltage DC (88 to 140 Vdc) 04: Legacy Low Voltage DC (20 to 30 Vdc) 05: Universal AC Voltage (85 to 264 Vac rms) 06: High Voltage DC Supply 07: Low Voltage DC Supply |
| B: Power Supply Type (Bottom Slot) |
00: No Supply (Used when no supply is required) 03: Legacy High Voltage DC (88 to 140 Vdc) 04: Legacy Low Voltage DC (20 to 30 Vdc) 05: Universal AC Voltage (85 to 264 Vac rms) 06: High Voltage DC Supply 07: Low Voltage DC Supply |
| C: Agency Approval |
00: None 01: CSA / NRTL / C (Class 1, Division 2) |
