Bently Nevada 3500/50M-01-00 3500/50M Tachometer Module
Bently Nevada 3500/50M-01-00 3500/50M Tachometer Module
Manufacturer: Bently Nevada
Product No.: 3500/50M-01-00
Condition:1000 in stock
Product Type: 3500/50M Tachometer Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 820g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
3500/50M-01-00 |
|
Description |
3500/50M Tachometer Module |
_
__ Description
The_3500/50M Tachometer Module_is a_2-channel module_that processes input from_proximity probes_or_magnetic pickups_to determine:
__Shaft rotative speed
__Rotor acceleration
__Rotor direction
The module compares these measurements against_user-programmable alarm setpoints_and generates alarms when limits are exceeded.
_
__ Specifications
Inputs
|
Attribute |
Value |
|---|---|
|
Signal Input |
Accepts up to_2 transducer signals_from proximity probes or magnetic pickups |
|
Input Signal Range |
+10.0 V to -24.0 V (signals exceeding this range are internally limited) |
|
Input Impedance |
20 k__(standard),_40 k__(TMR),_7.15 k__(Internal Barrier) |
|
Power Consumption |
5.8 Watts (typical) |
_
__ Physical Specifications
Monitor Module (Main Board)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 241.8 mm_(9.50 in x 0.96 in x 9.52 in) |
|
Weight |
0.82 kg_(1.8 lbs.) |
I/O Modules (Non-Barrier)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 99.1 mm_(9.50 in x 0.96 in x 3.90 in) |
|
Weight |
0.20 kg_(0.44 lbs.) |
I/O Modules (Internal Barrier)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 163.1 mm_(9.50 in x 0.96 in x 6.42 in) |
|
Weight |
0.46 kg_(1.01 lbs.) |
_
__ Ordering Information
|
Part Number |
Description |
|---|---|
|
3500/50M |
Tachometer Module |
Customization Options
|
Code |
I/O Module Type |
|---|---|
|
01 |
I/O Module with Internal Terminations |
|
02 |
I/O Module with External Terminations |
|
04 |
I/O Module with Internal Barriers and Internal Terminations |
|
Code |
Hazardous Area Approval Option |
|---|---|
|
00 |
None |
|
01 |
cNRTLus (Class 1, Division 2) |
|
02 |
ATEX/IECEx/CSA (Class 1, Zone 2) |
_
