Product Description
š¹ General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Model/Part Number |
3500/40M-01-00 |
|
Description |
3500/40M Proximitor Monitor |
Ā
š¹ Description
TheĀ 3500/40M Proximitor MonitorĀ is aĀ four-channel monitorĀ that accepts input signals fromĀ Bently Nevada proximity transducers. It processes these signals to provide vibration and position measurements and compares them againstĀ user-programmable alarms.
TheĀ 3500/40M channelsĀ can be configured using theĀ 3500 Rack Configuration SoftwareĀ for the following measurement functions:
ā¢Ā Radial vibration
ā¢Ā Eccentricity
ā¢Ā REBAM (Rolling Element Bearing Analysis Monitor)
ā¢Ā Thrust position
ā¢Ā Differential expansion
Ā
š¹ Specifications
Inputs
|
Attribute |
Value |
|---|---|
|
Signal Input |
AcceptsĀ 1 to 4Ā proximity transducer signals |
|
Power Consumption |
7.7 Watts, typical |
|
Input Impedance (Standard I/O) |
10 kā¦ (for Proximitor and acceleration inputs) |
Ā
š¹ Environmental Limits
|
Attribute |
Value |
|---|---|
|
Operating Temperature |
-30Ā°C to +65Ā°CĀ (-22Ā°F to +150Ā°F) with Internal/External Termination I/O Module |
|
0Ā°C to +65Ā°CĀ (32Ā°F to +150Ā°F) with Internal Barrier I/O Module (Internal Termination) |
|
|
Storage Temperature |
-40Ā°C to +85Ā°CĀ (-40Ā°F to +185Ā°F) |
|
Humidity |
95%, non-condensing |
Ā
š¹ Physical Specifications
Monitor Module (Main Board)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 241.8 mmĀ (9.50 in x 0.96 in x 9.52 in) |
|
Weight |
0.91 kgĀ (2.0 lbs.) |
I/O Modules (Non-Barrier)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 99.1 mmĀ (9.50 in x 0.96 in x 3.90 in) |
|
Weight |
0.20 kgĀ (0.44 lbs.) |
I/O Modules (Barrier)
|
Attribute |
Value |
|---|---|
|
Dimensions (H x W x D) |
241.3 mm x 24.4 mm x 163.1 mmĀ (9.50 in x 0.96 in x 6.42 in) |
|
Weight |
0.46 kgĀ (1.01 lbs.) |
Ā
š¹ Ordering Information
|
Part Number |
Description |
|---|---|
|
3500/40M |
Proximitor Monitor |
Customization Options
|
Code |
I/O Module Type |
|---|---|
|
01 |
Proximitor I/O Module with Internal Termination |
|
02 |
Proximitor I/O Module with External Terminations |
|
03 |
Proximitor I/O Module with Internal Barriers and Internal Terminations |
|
Code |
Hazardous Area Approval Option |
|---|---|
|
00 |
None |
|
01 |
cNRTLusĀ (Class 1, Division 2) |
|
02 |
ATEX / IECEx / CSAĀ (Class 1, Zone 2) |
Ā
