Product Description
Product Details
Manufacturer: Bently Nevada
Series: 3500/32
Model/Part Number: 184631-02
Model Type: 4-Channel Relay Module
Description
The 3500/32 4-Channel Relay Module is a full-height module designed to provide four relay outputs in the 3500 rack system. Multiple 4-Channel Relay Modules can be placed in the rack, specifically to the right of the Transient Data Interface Module.
Each relay on the module can be individually programmed to perform voting logic. The module includes Alarm Drive Logic, which allows users to configure the alarms based on AND and OR logic, using a variety of inputs such as:
- Alert and Danger statuses
- Not-OK
- Individual PPLs from any monitor channel or a combination of monitor channels in the rack
This flexibility allows users to tailor alarm and relay behaviors according to specific application requirements using the 3500 Rack Configuration Software.
Ordering Information
The part number format for the 3500/32 4-Channel Relay Module is 3500/32-AA-BB.
Field Breakdown:
-
A: Output Module
- 01: 4-Channel Relay Output Module
-
B: Agency Approval Option
- 00: None
- 01: CSA/NRTL/C (Class I, Div 2)
- 02: ATEX/IECEx/CSA (Class I, Zone 2)
