Bently Nevada 1900/65A 01-00-03-00-000 General Purpose Equipment Monitor

Bently Nevada 1900/65A 01-00-03-00-000 General Purpose Equipment Monitor

  • Manufacturer: Bently Nevada

  • Product No.: 1900/65A 01-00-03-00-000

  • Condition:1000 in stock

  • Product Type: General Purpose Equipment Monitor

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 770g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

šŸ”¹ General Information


Manufacturer

Bently Nevada

Series

–

Model/Part Number

1900/65A 01-00-03-00-000

Description

1900/65A General Purpose Equipment Monitor


Ā



Ā

šŸ”¹ Description



TheĀ 1900/65A General Purpose Equipment MonitorĀ is designed forĀ continuous monitoring and protectionĀ of machinery across a broad range of industries. It is aĀ cost-effectiveĀ solution for general-purpose machines where full-scale protection systems like the 3500 series may be excessive. It supports optional displays and various mounting options.

Ā



Ā

šŸ”¹ Power Requirements


Parameter

Specification

Input Voltage Range

18 to 36 Vdc

Operating Current

0.35 A typical, 1.0 A maximum

Operating Power

8.5 W typical, 14 W maximum


Ā



Ā

šŸ”¹ Physical



Ā

Monitor Module


Dimensions (L x W x H)

196.9 mm x 149.4 mm x 74.4 mm (7.75 in x 5.88 in x 2.93 in)

Weight

0.77 kg (1.70 lb)

Ā

Display Module


Dimensions (L x W x H)

196.9 mm x 149.4 mm x 32.8 mm (7.75 in x 5.88 in x 1.29 in)

Weight

0.40 kg (0.89 lb)


Ā



Ā

šŸ”¹ Environmental


Parameter

Specification

Operating Temperature

-20°C to +70°C (-4°F to +158°F)

Storage Temperature

-30°C to +90°C (-22°F to +194°F)


Ā



Ā

šŸ”¹ Ordering Information (for Model: 1900/65A 01-00-03-00-000)


Field

Code

Description

A

01

110 to 220 Vac @ 50 to 60 Hz (external supply)

B

00

No display

C

03

Fiberglass NEMA 4X/IP66 WP housing with window in door

D

00

No approvals

E

00

No communications option

Ā
