Product Description
Product Details
- Manufacturer: Bently Nevada
- Series: 1900/65A
- Model/Part Number: 1900/65A-00-00-01-00-00
- Model Type: General Purpose Equipment Monitor
Environmental Specifications
- Operating Temperature: -20 to +70 ºC (-4 to +158 ºF)
- Storage Temperature: -30 to +90 ºC (-22 to +194 ºF)
Physical Specifications
Monitor Module
- Dimensions (L x W x H): 196.9 mm x 149.4 mm x 74.4 mm (7.75 in x 5.88 in x 2.93 in)
- Weight: 0.77 kg (1.70 lb)
Technical Information
| Feature | Specification |
|---|---|
| Operating Temperature | -20 to +70 ºC (-4 to +158 ºF) |
| Storage Temperature | -30 to +90 ºC (-22 to +194 ºF) |
| Dimensions (L x W x H) | 196.9 mm x 149.4 mm x 74.4 mm (7.75 in x 5.88 in x 2.93 in) |
| Weight | 0.77 kg (1.70 lb) |
Ordering Information
- Model: 1900/65A General Purpose Equipment Monitor
- Part Number Format: 1900/65A-AA-BB-CC-DD-EE
A: Power Option
| Option | Description |
|---|---|
| 00 | 18 to 36 Vdc |
| 01 | 110 to 220 Vac @ 50 to 60 Hz (external supply) |
B: Display Option
| Option | Description |
|---|---|
| 00 | No display |
| 01 | Attached display (no cable) |
| 02 | Display with 10’ PVC cable |
| 03 | Display with 10’ unassembled PVC cable |
| 04 | Display with 10’ TEF cable |
| 05 | Display with 10’ unassembled TEF cable |
C: Mounting Option
| Option | Description |
|---|---|
| 00 | None |
| 01 | DIN rail mount |
| 02 | Bulkhead mount |
| 03 | Fiberglass NEMA 4X/IP66 WP housing with window in door |
| 04 | 1900/55 replacement kit |
| 07 | ProTIM Housing, Wiring, and Mounting Hardware |
D: Approvals Options
| Option | Description |
|---|---|
| 00 | None |
| 01 | Multiple approvals |
E: Communications Option
| Option | Description |
|---|---|
| 00 | None |
| 01 | Modbus communications |
