ALLEN BRADLEY 1783-BMS10CL Stratix 5700 10 Port Managed Switch

Temperature, surrounding air, max

60 °C (140 °F)

Enclosure type rating

None (open-style)

Switch power input, max

12…48V DC, 0.5 …3.0 A

PoE power input

44…57V DC, 2.5 A max

PoE+ power input

50…57V DC, 2.5 A max

Alarm relay

30V DC, 1.0 A, or 48V DC, 0.5 A

Isolation voltage

60V (continuous), basic insulation type, DC power ports to ground, and PoE power ports to ground

Wire size, DC power connections

0.5…0.8 mm² (20…18 AWG) solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper AWM wire

Wire size, ground connection

4.0 mm² (12 AWG) min, stranded copper wire

Wire size, alarm connections

0.5…0.8 mm² (20…18 AWG) solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper AWM wire

Screw torque, power terminals

0.23 N•m (2.0 in•lb)

Screw torque, ground terminals

0.4 N•m (3.5 in•lb)

Screw torque, alarm terminals

0.23 N•m (2.0 in•lb), max

Pilot duty rating

Alarm not rated

North American temp code

T4

ATEX temp code

T4
