Product Description
__ General Information
|
Category |
Details |
|---|---|
|
Manufacturer |
Allen-Bradley |
|
Model/Part Number |
1756-L85EK |
|
Description |
ControlLogix 5580 Controller with 40 MB User Memory, USB Port, Gigabit Ethernet, and support for large I/O counts. |
_
_
__ Technical Specifications
|
Attribute |
Details |
|---|---|
|
User Memory |
40 MB |
|
Digital I/O (Max) |
128,000 |
|
Analog I/O (Max) |
4,000 |
|
Total I/O (Max) |
128,000 |
|
Optional Nonvolatile Memory |
2 GB Secure Digital Card (1784-SD2), pre-installed |
|
Energy Storage Module |
Embedded in controller, non-removable |
|
Number of Power Cycles |
80,000 |
|
Current Draw @ 1.2V DC |
5.0 mA |
|
Current Draw @ 5.1V DC |
1.20 A |
|
Power Dissipation |
6.2 W |
|
Thermal Dissipation |
21.2 BTU/hr |
|
Residual Stored Energy |
Not Applicable |
|
Isolation Voltage |
50V (continuous), Basic Insulation type |
|
Compliant Standards |
IEC/UL 61010-1 |
|
Weight |
0.394 kg (0.868 lb) |
|
Slot Width |
1 |
|
Module Location |
Chassis-based, any slot |
|
Chassis Compatibility |
1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K, 1756-A17, 1756-A17K Series B, Series C |
|
Power Supply (Standard) |
1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, 1756-PB75K, 1756-PH75, 1756-PC75 |
|
Power Supply (Redundant) |
1756-PA75R, 1756-PA75RK, 1756-PB75R, 1756-PB75RK, 1756-PSCA2, 1756-PSCA2K |
|
Wire Category |
3 on USB port, 2 on Ethernet ports |
|
Wire Size |
Ethernet cabling and installation according to IEC 61918 and IEC 61784-5-2 |
|
Temperature Code |
T4 |
|
Enclosure Type Rating |
None (open-style) |
_
_
__ Key Features
|
Feature |
Description |
|---|---|
|
High-Speed Communication |
Gigabit Ethernet and USB connectivity for fast data transfer and diagnostics |
|
Large I/O Capacity |
Supports up to 128,000 digital I/O and 4,000 analog I/O |
|
Nonvolatile Storage |
2 GB Secure Digital Card pre-installed for reliable storage |
|
Energy Storage |
Embedded energy storage for uninterrupted operation |
|
Wide Compatibility |
Compatible with a variety of Allen-Bradley power supplies and chassis |
