Product Description
__ General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1747-BSN |
|
Description |
SLC 500 BACnet Communication Adapter |
|
Product Series |
SLC 500 |
_
__ Specifications
Operating Specifications
|
Specification |
Description |
|---|---|
|
Backplane Current Consumption |
800 mA at 5V |
|
Operating Temperature |
+32°F to +140°F (0°C to +60°C) |
|
Storage Temperature |
-40°F to +185°F (-40°C to +85°C) |
|
Humidity |
5 to 95% without condensation |
|
Noise Immunity |
NEMA Standard ICS 2-230 |
_
Agency Certification
|
Certification |
Description |
|---|---|
|
UL Listed |
Yes |
|
C-UL Listed |
Yes (Class I, Division 2, Groups A, B, C, D) |
|
Temperature Code |
T3C |
|
CE Compliant |
Yes (for all applicable directives) |
_
Baud Rate, Maximum Cable Distance, and Terminating Resistor Size
|
Baud Rate |
Maximum Cable Distance |
Terminating Resistor Size |
|---|---|---|
|
57.6K baud |
3048 meters (10,000 feet) |
150Ω 1/2 Watt (Brown-Green-Brown-Gold) |
|
115.2K baud |
1525 meters (5,000 feet) |
150Ω 1/2 Watt (Brown-Green-Brown-Gold) |
|
230.4K baud |
750 meters (2,500 feet) |
82Ω 1/2 Watt (Gray-Red-Black-Gold) |
_
