ALLEN BRADLEY 1738-AENT EtherNet/IP Adapter for POINT I/O Modules
ALLEN BRADLEY 1738-AENT EtherNet/IP Adapter for POINT I/O Modules
Manufacturer: ALLEN BRADLEY
Product No.: 1738-AENT
Condition:1000 in stock
Product Type: EtherNet/IP Adapter for POINT I/O Modules
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1738-AENT |
|
Description |
EtherNet/IP Adapter for POINT I/O Modules |
_
__ General Specifications
|
Attribute |
Specification |
|---|---|
|
Status Indicators |
- 3 red/green indicators on CPU: |
__Adapter Status
__Network Status
__POINTBus Status
__1 green indicator on CPU: Network Activity
__2 green indicators on DC-DC Converter:
__System Power (5V DC to POINTBus Out)
__Adapter Power (24V DC from Field In) |
|_Power Consumption (Max)_| 8.1 W @ 28.8V DC |
|_Power Dissipation (Max)_| 2.8 W @ 28.8V DC |
|_Thermal Dissipation (Max)_| 9.5 BTU/hr @ 28.8V DC |
|_Input Overvoltage Protection_| Reverse polarity protected |
|_Isolation Voltage_| Type tested @ 500V AC for 60 s:
__Communication to system
__Communication to user power
__User power to system
__User power to ground
__System to ground |
_
__ Field Power & Input Specifications
|
Attribute |
Specification |
|---|---|
|
Field Power Supply |
10_28.8V DC @ 10A |
|
Field Power Output |
10_28.8V DC @ 9A |
|
Module Input Voltage |
10_28V DC @ 1000 mA |
_
__ Physical & Environmental Specifications
|
Attribute |
Specification |
|---|---|
|
Dimensions (H x W x D) |
112.0 x 72.0 x 65.0 mm (4.41 x 2.83 x 2.56 in.) |
|
Mounting Type |
Metal panel |
|
Enclosure Type Rating |
Meets IP65/66/67/69K (when marked) |
|
Terminal Base Screw Torque |
0.8 Nm (7 lb-in) |
|
Weight |
0.36 Kg (0.8 lb) |
|
Wiring Category |
1 _ on power ports, 1 _ on communications ports |
_
_
