Product Description
🔹 General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1734SC-IF4U |
|
Description |
POINT I/O 4-Channel Universal Analog Input Module |
🔹 General Specifications
|
Parameter |
Specification |
|---|---|
|
Module Location |
1734-TBxx |
|
POINTBus Current |
15 mA |
|
Power Dissipation (Max) |
0.6 W @ 28.8 VDC |
|
Thermal Dissipation (Max) |
2.0 BTU/hr @ 28.8 VDC |
|
Isolation Voltage |
50V (continuous), Basic Insulation Type (Controller to Field) |
|
Channel-to-Channel Isolation |
Low level, non-galvanic |
|
Channel-to-Channel Voltage |
10V DC measured between IN- leads (5V DC for ±10V range) |
|
Max Voltage Between Any Two Pins |
24V DC |
|
Allowed Voltage on Any Input Pin from Field Ground |
±11V |
|
External DC Power - Supply Voltage (Nominal) |
24V DC |
|
External DC Power - Voltage Range |
10…28.8V DC |
|
External DC Power - Supply Current |
20 mA @ 24V DC |
|
Dimensions (H × W × D) |
56 × 12 × 75.5 mm (2.21 × 0.47 × 2.97 in.) |
|
Key Switch Position |
3 |
|
Enclosure Type Rating |
None (open-style) |
|
Wire Size |
Determined by installed terminal block |
|
Wiring Category |
2 - on signal ports |
|
Wire Type |
Shielded |
|
Terminal Base Screw Torque |
Determined by installed terminal block |
|
Weight (Approx.) |
35 g (1.235 oz.) |
