Product Description
🔹 General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1719-AENTR |
|
Description |
Ethernet Adapter Module for 1719 Remote I/O Modules |
🔹 Technical Specifications
|
Attribute |
Value |
|---|---|
|
Supply Connection |
Backplane bus |
|
Rated Voltage (Un) |
Use only with 1719-PSDC power supply module |
|
Power Dissipation |
3.0 W |
|
Power Consumption |
3.0 W |
🔹 Fieldbus & Ethernet Interface
|
Attribute |
Value |
|---|---|
|
Fieldbus Type |
EtherNet/IP |
|
Ethernet Connection Type |
RJ-45 (front connector) |
|
Transfer Rate (Max) |
- Full Duplex: 10 Mbps, 100 Mbps - Half Duplex: 100 Mbps |
|
Station Connection |
Direct to PCS/PLC or via hubs/switches |
|
Bus Length |
≤ 100 m (≤ 328 ft) (CAT 7 cable) SF/UTP (ISO/IEC 11801) |
|
Addressing |
IP address assigned via Ethernet |
|
Ethernet Address |
IP V4 (default: 0.0.0.0, auto IP, DHCP) |
|
Supported I/O Modules |
All 1719 remote I/O modules |
|
HART Communication |
Via Ethernet |
🔹 Internal Bus
|
Attribute |
Value |
|---|---|
|
Connection |
Backplane bus |
🔹 Compliance & Certifications
|
Attribute |
Standard |
|---|---|
|
Electromagnetic Compatibility |
Directive 2014/30/EU EN 61326-1:2013 |
|
Degree of Protection |
IEC 60529 |
|
Fieldbus Standard |
IEEE 802.3 |
|
Environmental Test |
EN 60068-2-14 |
|
Shock Resistance |
EN 60068-2-27 |
|
Vibration Resistance |
EN 60068-2-6 |
|
Damaging Gas |
EN 60068-2-42 |
|
Relative Humidity |
EN 60068-2-56 |
🔹 Environmental Conditions
|
Attribute |
Value |
|---|---|
|
Operating Temperature |
-20…+60°C (-4…+140°F) |
|
Storage Temperature |
-25…+85°C (-13…+185°F) |
|
Relative Humidity |
95% non-condensing |
|
Shock Resistance |
- Shock Type I - Duration: 11 ms - Amplitude: 15 g - Number of Shocks: 18 |
|
Vibration Resistance |
- 10…150 Hz (Transition: 57.56 Hz, ± 0.075 mm/1 g, 10 cycles) - 5…100 Hz (Transition: 13.2 Hz, ± 1 mm/0.7 g, 90 min at each resonance) |
|
Damaging Gas Compliance |
ISA-S71.04-1985, Severity Level G3 |
🔹 Mechanical Specifications
|
Attribute |
Value |
|---|---|
|
Degree of Protection |
IP20 (module), mounted on backplane |
|
Connection |
Via backplane |
|
Mass |
Approx. 150 g (5.29 oz) |
|
Dimensions (H x W x D) |
Approx. 32 x 100 x 103 mm (1.26 x 3.9 x 4 in) |
🔹 Ex-Area Application Data
|
Attribute |
Value |
|---|---|
|
Type Examination Certificate |
DEMKO 16 ATEX 1780X |
|
Group, Category, Type of Protection |
II 3 G Ex nA IIC T4 Gc |
|
Directive Conformity |
- Directive 2014/34/EU - EN 60079-0:2012+A11:2013 (General Requirements) - EN 60079-15:2010 (Protection “n” for Explosive Atmospheres) |
🔹 International Approvals
|
Approval Type |
Standard |
|---|---|
|
UL Approval |
E106378 |
|
IECEx Approval |
IECEx UL 16.0141X |
|
Ex-Proof Rating |
Ex nA IIC T4 Gc |
