Product Description
🔹 General Information
|
Manufacturer |
Allen-Bradley |
|---|---|
|
Model/Part Number |
1715-TADOF |
|
Description |
Termination Assembly for 1715-OF8I Analog Output Module |
🔹 Technical Specifications
|
Attribute |
Value |
|---|---|
|
Modules Supported |
1715-OF8I Analog Output Module |
|
Operating Voltage Range |
18-32V DC |
|
Power Requirements |
0-24 mA per channel @ 18-32V DC |
|
Compliance Voltage Slew Rate (Max) |
No limit identified within compliance voltage range |
|
Power Dissipation |
- System: 3.6W max - Field Loop: 0.64W per field loop |
|
Isolation Voltage |
- 50V (continuous), basic insulation type - I/O ports to backplane - 50V isolation between individual I/O ports - Type tested at 500V AC for 60s |
🔹 Mechanical Specifications
|
Attribute |
Value |
|---|---|
|
Weight |
- Termination Assembly: 133g (4.69 oz) / 260g (9.17 oz) |
|
Dimensions (H x W x D) |
132 x 84 mm (5.25 x 3.375 in.) |
|
Wire Size |
0.33-1.5 mm² (22-16 AWG) solid or stranded shielded copper wire, rated at 85°C (185°F) or greater |
|
Wiring Category |
2 - on shielded signal ports |
|
Wire Type |
Shielded |
|
Screw Torque |
0.5 N•m (0.37 lb•ft) |
|
Screwdriver Width |
Flathead 0.4 x 2.0 mm (0.0156 x 0.0781 in.) |
|
Fuses |
None |
🔹 Environmental Specifications
|
Attribute |
Value |
|---|---|
|
Temperature Rating |
- North American: T4 - IEC: T4 |
|
Enclosure Type |
None (Open-style) |
