Product Description
Product Overview
The Allen-Bradley 1715-OF8I is an Analog Output Module designed for industrial automation applications within Rockwell Automation systems. Manufactured by Allen-Bradley (a Rockwell Automation brand), this module is part of the 1715 Redundant I/O series, offering high availability for critical process control. It features eight isolated analog output channels delivering 4-20 mA signals, ideal for driving modulating devices in environments such as manufacturing, process industries, and industrial machinery. The module supports redundant configurations, ensuring continuous operation even during component failures.
Technical Specifications
The 1715-OF8I has the following specifications based on supplier data from Rockwell Automation and Radwell:
| Item | Specification |
|---|---|
| Model/Part Number | 1715-OF8I |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Description | Analog Output Module |
| Series | 1715 Redundant I/O |
| Output Channels | 8 (individually isolated) |
| Output Signal | 4-20 mA |
| Power Supply | 18-32 V DC |
| Power Consumption | 260 mA at 24 V DC |
| Operating Temperature | -25°C to 70°C (-13°F to 158°F) |
| Dimensions | 166 x 42 x 118 mm (6.54 x 1.65 x 4.65 in) |
| Weight | 0.36 kg (0.79 lbs) |
Additional Details
The 1715-OF8I includes the following additional information based on supplier documentation:
| Category | Details |
|---|---|
| Function | Drives modulating devices with 4-20 mA signals |
| Mounting | DIN rail (requires 1715-A310 base and 1715-TASOF8 or 1715-TADOF8 termination assembly) |
| Connectivity | Terminal base wiring |
| Features | Redundant I/O support, isolated channels, fault-tolerant design |
| Certifications | CE, UL Listed |
