Product Description
Product Overview
The ABB DSQC346G 3HAB8108-8 is a Servo Drive Unit designed for use in ABB’s industrial robotic systems, specifically within the S4C and S4C+ controller platforms for robots such as the IRB 140, IRB 2400, IRB 4400, or IRB 6400 series. Manufactured by ABB, this module is a key component of the robot’s drive system, controlling the servo motors that power the robot’s axes to achieve precise and dynamic motion. It is widely used in applications like welding, material handling, and assembly across industries such as automotive manufacturing, electronics, and general automation. The “DSQC346G” is the specific model designation, and “3HAB8108-8” is the catalog part number, often linked to revisions like 3HAB8101-8/08F, indicating its configuration within the DSQC346 family.
Technical Specifications
The DSQC346G 3HAB8108-8 has the following specifications based on supplier data and ABB robotics documentation:
| Item | Specification |
|---|---|
| Model/Part Number | DSQC346G (3HAB8108-8) |
| Manufacturer | ABB |
| Description | Servo Drive Unit |
| Series | S4C / S4C+ |
| Power Supply | 400-480 V AC, 50/60 Hz (via rectifier) |
| Output Power | 1.5 kW (confirmed for IRB servo motors) |
| Control Method | Vector control |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Weight | Approximately 3.5 kg (7.7 lbs) |
Additional Details
The DSQC346G 3HAB8108-8 includes the following additional information based on its standard use and supplier documentation:
| Category | Details |
|---|---|
| Function | Drives servo motors for robot axis control |
| Mounting | Installed in S4C/S4C+ controller rack |
| Connectivity | Interfaces with robot controller and motor cabling |
| Features | High reliability, precise motion control, compact design |
| Certifications | Designed for industrial standards (e.g., CE) |
