Yokogawa SSC10D-S2111 Duplexed Safety Control Unit
Yokogawa SSC10D-S2111 Duplexed Safety Control Unit
Manufacturer: Yokogawa
Product No.: SSC10D-S2111
Condition:1000 in stock
Product Type: Duplexed Safety Control Unit
Product Origin: Japan
Payment: T/T, Western Union
Weight: 8500g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
__ General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
SSC10D-S2111 |
|
Description |
Duplexed Safety Control Unit (for V net, Rack Mountable Type), standard temperature range with dual-redundant power and 100_120 V AC input |
_
_
__ Technical Specifications
|
Item |
Specification |
|---|---|
|
Processor |
MIPS R5000 Processor |
|
Main Memory |
32 MB |
|
Memory Protection |
Battery-backed (up to 3 years at _30°C) |
|
Temperature Adaptability |
Up to 50°C for -S model, fan required for higher ambient temperatures |
|
Communication Interfaces |
V net (dual-redundant), ESB bus (dual-redundant) |
|
IRIG Interface (Option) |
RS-422, IRIG-B000, 1 s frame time, 10 ms bit time |
|
Connected Safety Node Units |
Up to 9 per unit using ESB Bus coupler (SEC401 in slots 7 and 8) |
|
I/O Modules Supported |
Up to 8 per unit, up to 78 per Safety Control Station (SCS) |
|
Power Supply Voltage |
100 to 120 V AC, 50/60 Hz |
|
Power Consumption |
200 VA (for -S model with 100_120 V AC input) |
|
Weight |
Approx. 8.5 kg |
|
Mounting |
Rack mounting with 8 _ M5 screws, insulating bushings included |
|
Standards Compliance |
ISA Standard G3, installation environment per ProSafe-RS System Overview |
_
_
__ Model and Suffix Code Breakdown
|
Model |
Description |
|---|---|
|
SSC10D |
Duplexed Safety Control Unit (for V net, Rack Type) |
_
Suffix Codes
|
Code |
Meaning |
|---|---|
|
-S |
Standard Temperature (-20 to 50 °C), with ISA Standard G3 |
|
2 |
Dual-redundant power supply |
|
1 |
Always 1 (system definition) |
|
1 |
100 to 120 V AC power supply |
|
1 |
CFS1100 Safety Control Function License |
_
Full Code:
SSC10D-S2111
_
-
Standard temp version
-
Dual-redundant power supply
-
100_120 V AC power
-
Safety control function license included
_
_
__ Optional Codes
|
Option Code |
Description |
|---|---|
|
/GPS |
IRIG interface for GPS (Part Number: S9161FA) |
|
/ATDOC |
Explosion Protection Manual |
_
_
_
