Product Description
Product Details
| Manufacturer | Yokogawa |
|---|---|
| Model/Part Number | ACG10S-F2121 S4 |
| Description | Communication Gateway Unit (Frame Mode) |
General Overview
The ACG10S-F2121 S4 is a Communication Gateway Unit (CGW) that enables seamless communication between multiple fieldbus networks, providing interoperability between devices from different manufacturers. It supports a variety of protocols, including PROFIBUS, PROFIBUS DP, MODBUS, and Ethernet IP. This device also features robust security measures, ensuring data integrity and confidentiality during transmission. It's ideal for integrating devices from multiple networks, making it versatile in industrial and automation settings.
Key Specifications
| Specification | Details |
|---|---|
| Communication Mode | Frame Mode, Wide Area Communication (Ethernet) |
| Redundancy | Dual-Redundant Vnet (10BASE-5) |
| Mounting Type | General-Purpose 19” Rack Mountable |
| Power Supply | 100-120 VAC |
| Weight | Approx. 7.5 kg (Rack Mount Type) |
| Approx. 6.5 kg (Desktop Type) |
Software Functions
- LGW1240: Text Mode Gateway Unit Function
- LGW1250: Frame Mode, Wide Area Communication Gateway Unit Function
This ACG10S-F2121 S4 gateway unit is particularly useful in environments where diverse devices with varying communication protocols need to be integrated into a cohesive network. The frame mode allows for broader communication across wide areas, while its redundancy ensures reliability.
