| Specification |
Details |
| Model |
TUG-416 8441-1013 |
| Type |
Gas Turbine Control Unit (Governor) |
| Power Supply |
24 VDC nominal (18–32 VDC, estimated based on similar Woodward units) |
| Control Signal |
Analog, 4–20 mA or 0–200 mA for actuators (estimated) |
| Speed Inputs |
Magnetic Pickup Unit (MPU), 100 Hz–20 kHz (estimated) |
| Analog Inputs |
4–20 mA, configurable (exact number not specified) |
| Discrete Inputs |
Not specified (typically 8–16 in similar units) |
| Outputs |
Actuator outputs, relay outputs (exact number not specified) |
| Communication |
Not specified (likely RS-232/RS-485 or Modbus in similar units) |
| Operating Temperature |
-40°C to +70°C (-40°F to +158°F) (estimated, based on Woodward standards) |
| Storage Temperature |
-55°C to +105°C (-67°F to +221°F) (estimated) |
| Relative Humidity |
5% to 95%, non-condensing |
| Vibration |
4 G, 5–500 Hz |
| Shock |
20 G peak |
| Protection Rating |
Not specified (designed for control cabinet use) |
| Dimensions |
Not specified (compact for panel or rack mounting) |
| Weight |
Approximately 2–4 kg (4.4–8.8 lbs, estimated) |
| Mounting |
Panel or rack mount |
| Certifications |
CE, UL/cUL (estimated for industrial environments) |
| System Compatibility |
Woodward actuators, gas turbines, MicroNet or NetCon systems |
