Woodward SST-ESR2-CLX-RLL Ethernet ControlLogix Module
Woodward SST-ESR2-CLX-RLL Ethernet ControlLogix Module
Manufacturer: Woodward
Product No.: SST-ESR2-CLX-RLL
Condition:1000 in stock
Product Type: Ethernet ControlLogix Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Woodward SST-ESR2-CLX-RLL Ethernet ControlLogix Module
Product Overview
- The Woodward SST-ESR2-CLX-RLL is an Ethernet ControlLogix Module designed for interfacing Rockwell Automation ControlLogix programmable logic controllers (PLCs) with Ethernet-based industrial networks in power generation, industrial automation, and process control applications. This communication module, part of Woodward__ SST (SynchroNet Systems Technology) product line, enables seamless data exchange between ControlLogix PLCs and devices using Ethernet protocols, such as Modbus TCP, EtherNet/IP, or other industrial communication standards. The "CLX" indicates compatibility with the ControlLogix platform, and "RLL" refers to its integration with Rockwell__ Relay Ladder Logic programming environment. The module is ideal for integrating Woodward control systems (e.g., turbine or genset controllers) with PLC-based automation systems in power plants, marine applications, and industrial facilities. Compared to Woodward__ genset controllers (e.g., EasyGen-3500-5, 8440-2087), protection relays (e.g., XD1G11), or excitation systems (e.g., DECS-100-B15), the SST-ESR2-CLX-RLL is a communication interface, not a control or protection device. It is distinct from Woodward__ electronic governors (e.g., DYN1-10784-003-0-12), actuators (e.g., 8408-921), and other modules (e.g., 5466-1510 CPU).
Technical Specifications
- The SST-ESR2-CLX-RLL has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | SST-ESR2-CLX-RLL |
| Manufacturer | Woodward |
| Description | Ethernet ControlLogix Communication Module |
| Series | SST |
| Function | Interfaces ControlLogix PLCs with Ethernet-based industrial networks |
| Processor | Embedded microprocessor (specific architecture not publicly detailed) |
| Memory | Flash: 8_16 MB (for firmware and configuration) RAM: 4_8 MB (for runtime data) |
| Display | LED indicators for status, network activity, and faults |
| Inputs | None (data input via Ethernet or ControlLogix backplane) |
| Outputs | None (data output via Ethernet or ControlLogix backplane) |
| Communication Interfaces | 2 Ethernet ports (10/100 Mbps, RJ45, supports Modbus TCP, EtherNet/IP) ControlLogix backplane interface (for PLC communication) Serial port (optional, for configuration) |
| Supported Protocols | Modbus TCP (client/server), EtherNet/IP (implicit/explicit messaging), OPC (optional with software), custom protocols (configuration-dependent) |
| Data Transfer Rate | Up to 100 Mbps (Ethernet) |
| Redundancy | Non-redundant (network redundancy possible with external switches) |
| Diagnostics | Network status, communication errors, event logging (via PLC or software), status LEDs |
| Compatibility | Rockwell Automation ControlLogix PLCs (e.g., 1756 series); Woodward control systems (e.g., MicroNet, EasyGen); third-party devices via Modbus TCP or EtherNet/IP; integrates with SCADA/DCS systems |
| Power Supply | 5 VDC (via ControlLogix backplane) |
| Power Consumption | Approx. 3_5 W |
| Environmental Specifications | Operating Temperature: 0°C to +60°C (32°F to +140°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Enclosure | IP20 (open-style module, installed in ControlLogix chassis) |
| Dimensions | Approx. 145 mm (H) x 35 mm (W) x 140 mm (D) |
| Weight | Approx. 0.3_0.5 kg |
| Mounting | Plugs into ControlLogix chassis (1756 series) |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS, configuration-dependent) |
