Product Description
Woodward IRI1-I5E05D Current Relay
Product Overview
- The Woodward IRI1-I5E05D is a digital current relay designed for overcurrent protection in electrical systems, commonly used in power generation, distribution, and industrial applications such as generator sets, motors, and transformers. Part of Woodward’s IRI1 series, this microprocessor-based relay provides reliable monitoring and protection against overcurrent conditions, ensuring the safety and stability of connected equipment. The IRI1-I5E05D model is configured for specific current and voltage inputs, with the "I5E05D" designation indicating a 5 A nominal current input, extended functionality, and specific firmware or hardware features. It offers precise protection settings, fault diagnostics, and communication capabilities for integration into modern power management systems. Compared to Woodward’s genset controllers (e.g., EasyGen-3500-5, 8440-2087), excitation systems (e.g., DECS-100-B15), or transfer switch controllers (e.g., DTSC-200), the IRI1-I5E05D focuses solely on current-based protection, not engine or generator control. It is distinct from Woodward’s electronic governors (e.g., DYN1-10784-003-0-12), actuators (e.g., 8408-921), and other modules (e.g., 5466-1510 CPU).
Technical Specifications
- The IRI1-I5E05D has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | IRI1-I5E05D |
| Manufacturer | Woodward |
| Description | Digital Current Relay for Overcurrent Protection |
| Series | IRI1 |
| Function | Monitors and protects against overcurrent conditions in electrical systems |
| Processor | Microprocessor-based (specific architecture not publicly detailed) |
| Memory | Flash: 4–8 MB (for firmware and configuration) RAM: 2–4 MB (for runtime data) |
| Display | LED indicators; optional external HMI for configuration |
| Inputs | 3-phase current inputs (5 A nominal, 1–40 A range) 1 auxiliary voltage input (24–270 V AC/DC, configuration-dependent) 2 discrete inputs (24 VDC) |
| Outputs | 3 relay outputs (dry contact, up to 250 VAC/5 A) 1 analog output (optional, 4–20 mA) |
| Communication Interfaces | 1 serial port (RS-485, Modbus RTU) CANbus (optional, for integration with control systems) |
| Protection Functions | Overcurrent (instantaneous and time-delayed), short-circuit protection, inverse time characteristics (ANSI/IEC curves) |
| Trip Accuracy | ±5% of set value |
| Protection Settings | Configurable trip thresholds, time delays, and characteristic curves |
| Redundancy | Non-redundant |
| Diagnostics | Fault detection, event logging (up to 100 events), status LEDs |
| Compatibility | Compatible with Woodward genset controllers (e.g., EasyGen-3200-5, 8440-2050), SCADA systems, and third-party devices via Modbus; suitable for generator, motor, and transformer protection |
| Power Supply | 24–270 V AC/DC (universal input) |
| Power Consumption | Approx. 5–10 W |
| Environmental Specifications | Operating Temperature: -25°C to +70°C (-13°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Enclosure | IP40 (with proper enclosure); IP20 (rear) |
| Dimensions | Approx. 100 mm (H) x 110 mm (W) x 90 mm (D) |
| Weight | Approx. 0.5–1 kg |
| Mounting | Panel-mounted or DIN rail |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS, configuration-dependent) |
