Woodward DC70025-003-112 DYNA 70025 Actuator

Woodward DC70025-003-112 DYNA 70025 Actuator

  • Manufacturer: Woodward

  • Product No.: DC70025-003-112

  • Condition:1000 in stock

  • Product Type: DYNA 70025 Actuator

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 4500g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Woodward DC70025-003-112 DYNA 70025 Actuator

  • Manufacturer: Woodward (now manufactured by QCC for some units)
  • Model/Part Number: DC70025-003-112
  • Description: DYNA 70025 Rotary Actuator, 12 VDC, Sealed Unit, for Stanadyne "D" Series Rotary Fuel Injection Pumps

Overview

  • The Woodward DC70025-003-112 is a DYNA 70025 rotary actuator designed for integrated installation on Stanadyne "D" series rotary fuel injection pumps. It provides precise control of fuel delivery in diesel engines, commonly used in applications such as John Deere 3029 and 4045 engines, industrial equipment, and marine systems. The sealed unit enhances durability in harsh environments.

Technical Specifications

Specification Details
Model DC70025-003-112
Series DYNA 70025 (APECS Rotary)
Type Rotary Actuator
Power Supply 12 VDC
Speed Range 250–9500 Hz
Operating Temperature -40°C to +125°C (-40°F to +257°F)
Storage Temperature -40°C to +125°C (-40°F to +257°F)
Weight 0.8 kg (1 lb 12 oz)
Sealing Sealed unit, no O-ring or seal kit
Vibration Not specified (designed for rugged environments)
Protection Rating Not specified (sealed for environmental resistance)
Dimensions Approximately 16 cm x 11 cm x 22 cm (6.3 in x 4.3 in x 8.7 in) (shipping dimensions)
Mounting Integrated installation on Stanadyne "D" series pumps
Certifications Not specified
System Compatibility Stanadyne "D" series rotary fuel injection pumps, John Deere 3029/4045 engines, Woodward APECS controllers



View full details

Product Description

Woodward DC70025-003-112 DYNA 70025 Actuator

  • Manufacturer: Woodward (now manufactured by QCC for some units)
  • Model/Part Number: DC70025-003-112
  • Description: DYNA 70025 Rotary Actuator, 12 VDC, Sealed Unit, for Stanadyne "D" Series Rotary Fuel Injection Pumps

Overview

  • The Woodward DC70025-003-112 is a DYNA 70025 rotary actuator designed for integrated installation on Stanadyne "D" series rotary fuel injection pumps. It provides precise control of fuel delivery in diesel engines, commonly used in applications such as John Deere 3029 and 4045 engines, industrial equipment, and marine systems. The sealed unit enhances durability in harsh environments.

Technical Specifications

Specification Details
Model DC70025-003-112
Series DYNA 70025 (APECS Rotary)
Type Rotary Actuator
Power Supply 12 VDC
Speed Range 250–9500 Hz
Operating Temperature -40°C to +125°C (-40°F to +257°F)
Storage Temperature -40°C to +125°C (-40°F to +257°F)
Weight 0.8 kg (1 lb 12 oz)
Sealing Sealed unit, no O-ring or seal kit
Vibration Not specified (designed for rugged environments)
Protection Rating Not specified (sealed for environmental resistance)
Dimensions Approximately 16 cm x 11 cm x 22 cm (6.3 in x 4.3 in x 8.7 in) (shipping dimensions)
Mounting Integrated installation on Stanadyne "D" series pumps
Certifications Not specified
System Compatibility Stanadyne "D" series rotary fuel injection pumps, John Deere 3029/4045 engines, Woodward APECS controllers
