| Specification |
Details |
| Model |
BL1840024 (BL18-400-24V-3P) |
| Type |
Battery Charger |
| Input Voltage |
3-phase, 360–530 VAC |
| Input Frequency |
50/60 Hz |
| Input Current |
1.5 A at 400 VAC |
| Output Voltage |
Adjustable 24–27.5 VDC |
| Output Current |
Not specified (typically 10–20 A, based on similar models) |
| Mode |
Mod 2 (specific charging profile, details in manual) |
| Operating Temperature |
-20°C to +60°C (-4°F to +140°F) (estimated, based on similar Woodward chargers) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) (estimated) |
| Relative Humidity |
5% to 95%, non-condensing (estimated) |
| Vibration |
4 G, 5–500 Hz (estimated, based on Woodward standards) |
| Shock |
20 G peak (estimated) |
| Protection Rating |
Not specified (designed for control cabinet use) |
| Dimensions |
Not specified (compact design, typically DIN rail or panel mount) |
| Weight |
1.43 kg (3.15 lbs) |
| Mounting |
Panel or DIN rail mount |
| Certifications |
CE (assumed, based on Woodward standards) |
| System Compatibility |
24 VDC battery systems, Woodward control systems (e.g., MicroNet, 505, 2301A) |
