Woodward B8561-697 CPU Processor Module

Woodward B8561-697 CPU Processor Module

  • Manufacturer: Woodward

  • Product No.: B8561-697

  • Condition:1000 in stock

  • Product Type: CPU Processor Module

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Woodward B8561-697 CPU Processor Module

  • Manufacturer: Woodward
  • Model/Part Number: B8561-697 (also referenced as 5464-697 in some listings)
  • Description: MicroNet CPU Processor Module, 24 VDC, for MicroNet Control Systems

Overview

  • The Woodward B8561-697 is a CPU Processor Module designed for use in Woodward’s MicroNet control systems. It serves as the central processing unit for managing control, communication, and I/O operations in industrial applications such as gas turbines, steam turbines, and power generation systems. This module is suitable for high-reliability environments like marine, industrial, and energy sectors.

Technical Specifications

Specification Details
Model B8561-697 (5464-697)
Series MicroNet
Type CPU Processor Module
Power Supply 24 VDC nominal (18–32 VDC), supplied via MicroNet chassis
Processor 32-bit microprocessor
Communication Protocols ControlNet, LINKnet, optional Modbus RTU (RS-232/RS-485)
Data Rate Up to 1 Mbps (ControlNet/LINKnet)
Memory Flash and RAM for program and data storage (specific sizes not publicly specified)
Operating Temperature -40°C to +70°C (-40°F to +158°F)
Storage Temperature -55°C to +105°C (-67°F to +221°F)
Relative Humidity 5% to 95%, non-condensing
Vibration 4 G, 5–500 Hz
Shock 30 G peak
Protection Rating Not specified (designed for control cabinet use)
Dimensions Approximately 150 mm x 100 mm x 50 mm (5.91 in x 3.94 in x 1.97 in)
Weight Approximately 0.5 kg (1.1 lbs)
Mounting Card guides in MicroNet chassis, secured with screws
Certifications CE, UL/cUL (for industrial environments)
System Compatibility Woodward MicroNet, MicroNet Plus, NetCon control systems
